Ford Ranger T6.2 (2022-2024) key release interlock actuator Wiring diagrams
This page contains all the electrical diagrams for the component. key release interlock actuator, in which he is found in the car Ford Ranger T6.2 (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram key release interlock actuator (1 of 2)
AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE)
BATTERY ENERGY CONTROL MODULE B (BECMB)
BODY CONTROL MODULE (BCM) (LEFT END OF DASH)
BRN WIRE
DATA LINK CONNECTOR (DLC)
FROM FUSE 18 (DIAGRAM 4 OF 8)
FROM HIGH CURRENT BATTERY JUNCTION BOX (BJB) (DIAGRAM 1 OF 8)
FUSE 10
FUSE 11
FUSE 14
FUSE 15
FUSE 17
FUSE 18
FUSE 2
FUSE 25
FUSE 26
FUSE 27
FUSE 28
FUSE 29
FUSE 30
FUSE 5
FUSE 56
FUSE 63
FUSE 64
FUSE 71
FUSE 73
FUSE 87
FUSE 9
GATEWAY MODULE A (GWM)
GRN WIRE
GRY WIRE
KEY RELEASE INTERLOCK ACTUATOR
LEFT FRONT DOOR WINDOW CONTROL SWITCH
ORG/ WIRE
RED WIRE
TAPED TO HARNESS NEAR LEFT KICK PANEL
TELEMATICS CONTROL UNIT (TCU) MODULE
TO CENTRAL UNLOCK RELAY (DIAGRAM 6 OF 8)
TO IGNITION SWITCH (DIAGRAM 8 OF 8)
TRAILER MODULE (TRM)
TRAILER TOW BACKUP LAMP RELAY
TRAILER TOW LH STOP/TURN RELAY
TRAILER TOW PARK LAMP RELAY
TRAILER TOW RH STOP/TURN RELAY
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (5 of 8) -> KEY RELEASE INTERLOCK ACTUATOR
Wiring diagram key release interlock actuator (2 of 2)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
BPP
BPS
BRAKE PEDAL POSITION (BPP) SWITCH
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BSI
BSI (FET)
CAN (+)
COMPUTER DATA LINES SYSTEM
FUSE 18
FUSE 47
FUSE 67
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
IGNITION SWITCH
INSTRUMENT PANEL CLUSTER (IPC)
KEY
KEY IN IGNITION
KEY INHIBIT (FET)
KEY RELEASE INTERLOCK ACTUATOR
MICRO -
NCA WIRE
ORG/ WIRE
PARK DETECT
PARK DETECT SWITCH
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
RTN
SELECTOR LEVER ASSEMBLY
SHIFT LOCK SOLENOID
SIGRTN
SST-D
SST-U
TRANSMISSION ASSEMBLY
TRANSMISSION RANGE (TR) SENSOR
TRANSMISSIONS SYSTEM
TRGND
TRP 1
TRP 2
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Shift interlock circuit -> KEY RELEASE INTERLOCK ACTUATOR
