Ford Ranger T6.2 (2022-2024) air intake shutoff valve Wiring diagrams
This page contains all the electrical diagrams for the component. air intake shutoff valve, in which he is found in the car Ford Ranger T6.2 (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram air intake shutoff valve (1 of 2)
4/7-WAY TRAILER TOW
AIR INTAKE SHUTOFF VALVE
AVC-
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
BPP
BPS
BRAKE FLUID
BRAKE FLUID LEVEL SWITCH
BRAKE PEDAL POSITION (BPP) SWITCH
BRAKE VACUUM SENSOR
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
FUSE 4
GRN/BLU WIRE
GRY WIRE
GRY/VIO WIRE
LEFT REAR WHEEL SPEED SENSOR
MICRO -
NCA WIRE
PARK BRAKE
PARKING BRAKE WARNING INDICATOR SWITCH
POWERTRAIN CONTROL MODULE (PCM)
RIGHT REAR WHEEL SPEED SENSOR
TAPED TO HARNESS NEAR LEFT KICK PANEL
VIO/BRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL/ORG WIRE
Go to component -> Anti-lock brakes circuit (2 of 2) -> AIR INTAKE SHUTOFF VALVE
Wiring diagram air intake shutoff valve (2 of 2)
AIR CONDITIONING (A/C) COMPRESSOR CONTROL SOLENOID
AIR INTAKE SHUTOFF VALVE
BATTERY
BATTERY MONITORING SENSOR
BATTERY MOUNTED FUSE LINK (BMFL)
BLU WIRE
CABIN HEATER COOLANT PUMP
COOLING FAN MOTOR
EVAPORATIVE EMISSION (EVAP) CANISTER VENT VALVE
EVAPORATIVE EMISSION (EVAP) PURGE VALVE
EVAPORATIVE EMISSION (EVAP) VAPOR BLOCKING VALVE
FUSE 1
FUSE 12
FUSE 2
FUSE 3
FUSE 7
FUSE 8
GENERATOR
GRN WIRE
GRY WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
MEGA FUSE 5
NCA WIRE
PCM POWER RELAY
POWER STEERING CONTROL MODULE (PSCM)
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
STARTER MOTOR
TO BODY CONTROL MODULE (BCM) (DIAGRAM 5 OF 8)
TO FUSE 11 (DIAGRAM 3 OF 8)
TO FUSE 53 (DIAGRAM 3 OF 8)
TO UPFITTER RELAY BOX (DIAGRAM 2 OF 8)
TRANSMISSION FLUID HEATER COOLANT CONTROL VALVE
TURBOCHARGER BYPASS (TCBY) VALVE
VARIABLE OIL PUMP
YEL WIRE
Go to component -> Power distribution circuit (1 of 8) -> AIR INTAKE SHUTOFF VALVE
