Ford Ranger T6 facelift 2 (2019-2022) taped to harness near left kick panel Wiring diagram
This page shows the only wiring diagram for the component.taped to harness near left kick panel, which is found in the car Ford Ranger T6 facelift 2 (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram taped to harness near left kick panel (1 of 1)
AIR INTAKE SHUTOFF VALVE
AVC-
BLK WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BPP
BPS
BRAKE FLUID
BRAKE FLUID LEVEL SWITCH
BRAKE PEDAL POSITION (BPP) SWITCH
BRAKE VACUUM SENSOR
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE
FUSE 13
FUSE 3
FUSE 4
GRN/BLU WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/VIO WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
LEFT REAR WHEEL SPEED SENSOR
MICRO -
NCA WIRE
PARK BRAKE
PARKING BRAKE WARNING INDICATOR SWITCH
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL MODULE (PCM)
PWR OUT
RED WIRE
RIGHT REAR WHEEL SPEED SENSOR
STEERING COLUMN CONTROL MODULE (SCCM)
TAPED TO HARNESS NEAR LEFT KICK PANEL
VBATT
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL/ORG WIRE
Go to component -> Anti-lock brakes circuit (2 of 2) -> TAPED TO HARNESS NEAR LEFT KICK PANEL
