Ford Ranger T6 facelift 2 (2019-2022) diff lock Wiring diagram
This page shows the only wiring diagram for the component.diff lock, which is found in the car Ford Ranger T6 facelift 2 (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram diff lock (1 of 1)
ACCR
ACCV
AIR CONDITIONING SYSTEM
AVC-
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CKCP
COMPUTER DATA LINES SYSTEM
CTRL
DIFF LOCK
ENG START SIG
ENS
FLP
FPC
FPM
FUEL PUMP RELAY
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 28
FUSE 45
FUSE 47
FUSE 60
FUSE 7
FUSE 8
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
IAT
ISP-R
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM) (LEFT SIDE OF ENGINE COMPT)
PWR GND
SMC
SMCS
STARTING/ CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TFHCCV
TFT
TRANSMISSIONS SYSTEM
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/RED WIRE
VIO/WHT WIRE
VPWR
WAKE-UP
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 2.3l turbo (2 of 9) -> DIFF LOCK
