Ford Ranger T6 facelift 2 (2019-2022) blk Wiring diagrams

This page contains all the electrical diagrams for the component. blk, in which he is found in the car Ford Ranger T6 facelift 2 (2019-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

blk wiring diagram (1 of 43)

BATTERY JUNCTION BOX (BJB) BLIS IND BLIS VPWR BLK WIRE BLK/BLU WIRE BLU WIRE BLU/BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE FUSE 23 HOT W/ RUN/START RELAY ENERGIZED IGN OUT LEFT EXTERIOR MIRROR LEFT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED LEFT REAR LAMP ASSEMBLY MS CAN + POWER DISTRIBUTION SYSTEM RIGHT EXTERIOR MIRROR RIGHT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED RIGHT REAR LAMP ASSEMBLY VPWR WHT WIRE WHT/BRN WIRE YEL WIRE YEL/GRN WIRE

Go to component -> Blind spot information system circuit -> BLK WIRE

blk wiring diagram (2 of 43)

AMBIENT LTG (FET) BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLU/RED WIRE BODY CONTROL MODULE (BCM) BRN/GRN WIRE BRN/RED WIRE CHMSL LAMP COURTESY DEMAND DEMAND LP/BATT SAVE (FET) DOME FUSE 2 FUSE 62 FUSE 67 GLOVE COMPARTMENT LAMP GRN/RED WIRE GRY/VIO WIRE HIGH CURRENT BATTERY JUNCTION BOX (BJB) HIGH MOUNTED STOP LAMP HOT AT ALL TIMES ILLUM INSTRUMENT ILLUMINATION CIRCUIT INT LTG (FET) LAMP CONTROL LEFT CARGO LAMP LEFT EXTERIOR MIRROR LEFT VANITY MIRROR LAMP MICRO - NCA WIRE OVERHEAD CONSOLE PUDDLE PUDDLE LAMP (FET) REAR INTERIOR LAMP RED WIRE RIGHT CARGO LAMP RIGHT EXTERIOR MIRROR RIGHT VANITY MIRROR LAMP STOP/ CHMSL (FET) VIO/GRY WIRE W/ LED W/O LED WHT/GRN WIRE YEL/GRN WIRE YEL/GRY WIRE

Go to component -> Courtesy lamps circuit (1 of 2) -> BLK WIRE

blk wiring diagram (3 of 43)

BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/VIO WIRE BLU WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/WHT WIRE CARGO CARGO LAMP SWITCH COMPUTER DATA LINES SYSTEM FRONT BIN AMBIENT LAMP GRN WIRE GRN/RED WIRE GRN/VIO WIRE INSTRUMENT ILLUMINATION CIRCUIT LEFT FRONT DOOR LATCH LEFT FRONT DOOR RELEASE AMBIENT LAMP LEFT FRONT FOOTWELL LAMP LEFT REAR DOOR AJAR SWITCH LEFT REAR DOOR LATCH LF DOOR AJAR LIN 13 LIN 15 LOGIC GND LR DOOR AJAR MICRO - OPEN CLOSED PWR RF DOOR AJAR RIGHT FRONT DOOR LATCH RIGHT FRONT DOOR RELEASE AMBIENT LAMP RIGHT FRONT FOOTWELL LAMP RIGHT REAR DOOR AJAR SWITCH RIGHT REAR DOOR LATCH RR DOOR AJAR SUPER CREW CAB VIO/GRY WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE YEL WIRE

Go to component -> Courtesy lamps circuit (2 of 2) -> BLK WIRE

blk wiring diagram (4 of 43)

AMPLIFIER BATTERY BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER MOTOR CONTROL MODULE BRAKE PEDAL POSITION (BPP) SWITCH CABIN HEATER COOLANT PUMP CRUISE CONTROL MODULE (CCM) DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE ELECTRONIC LOCKING DIFFERENTIAL (ELD) FIELD COIL IGNITION COIL ON PLUG 1 IGNITION COIL ON PLUG 2 IGNITION COIL ON PLUG 3 IGNITION COIL ON PLUG 4 INSTRUMENT PANEL POWER POINT 1 INSTRUMENT PANEL POWER POINT 2 LEFT EXTERIOR MIRROR LEFT FRONT DOOR LOCK SWITCH LEFT FRONT DOOR RELEASE AMBIENT LAMP LEFT FRONT DOOR WINDOW CONTROL SWITCH LEFT FRONT SIDE MARKER LAMP POWERTRAIN CONTROL MODULE (PCM) REAR OF ENGINE COMPT) RIGHT FRONT FOG LAMP RIGHT FRONT SIDE MARKER LAMP RIGHT HEADLAMP ASSEMBLY TAPED TO HARNESS NEAR LHS KICK PANEL TOP OF ENGINE) TRAILER TOW CONNECTOR (4 PIN) TRAILER TOW CONNECTOR (7 PIN) W/ AMBIENT LIGHTING WHT WIRE WINDSHIELD WASHER FLUID LEVEL SENSOR

Go to component -> Ground distribution circuit (1 of 5) -> BLK WIRE

blk wiring diagram (5 of 43)

BLK WIRE BLK/GRN WIRE BLK/WHT WIRE CARGO BOX POWER POINT CHASSIS CAB GRN WIRE HEATED WIPER PARK GRID HIGH MOUNTED STOP LAMP LEFT EXTERIOR MIRROR LEFT HEADLAMP ASSEMBLY LEFT LICENSE PLATE LAMP LEFT REAR LAMP ASSEMBLY NCA WIRE REAR OF ENGINE COMPT) REAR WINDOW DEFROST GRID RIGHT EXTERIOR MIRROR RIGHT HEADLAMP ASSEMBLY RIGHT LICENSE PLATE LAMP RIGHT REAR LAMP ASSEMBLY W/O BLIS

Go to component -> Ground distribution circuit (2 of 5) -> BLK WIRE

blk wiring diagram (6 of 43)

ANTI-LOCK BRAKE SYSTEM (ABS) MODULE BATTERY ENERGY CONTROL MODULE B (BECMB) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/WHT WIRE BLOWER MOTOR RELAY CLOCKSPRING DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER EXTERIOR MIRROR CONTROL SWITCH GATEWAY MODULE A (GWM) GLOVE COMPARTMENT LAMP GRY WIRE HAZARD SWITCH HORN SWITCH LEFT STEERING WHEEL SWITCH LEFT VANITY MIRROR LAMP NCA WIRE OVERHEAD CONSOLE POWER STEERING CONTROL MODULE (PSCM) REAR INTERIOR LAMP RIGHT EXTERIOR MIRROR RIGHT FRONT DOOR LOCK SWITCH RIGHT FRONT DOOR RELEASE AMBIENT LAMP RIGHT STEERING WHEEL SWITCH RIGHT VANITY MIRROR LAMP TRAILER TOW BACKUP LAMP RELAY TRANSMISSION RELAY VIO WIRE W/ AMBIENT LIGHTING W/O SYNC WINDSHIELD WASHER PUMP WINDSHIELD WIPER MOTOR

Go to component -> Ground distribution circuit (4 of 5) -> BLK WIRE

blk wiring diagram (7 of 43)

AUTOLAMP BACK LIGHT (FET) BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/VIO WIRE BLU WIRE BLU/RED WIRE BODY CONTROL MODULE (BCM) BRN/BLU WIRE BRN/YEL WIRE CAN (+) CARGO LAMP SWITCH CLOCKSPRING COMPUTER DATA LINES SYSTEM DIM + FUSE 23 FUSE 67 GRY WIRE H/L ON HAZARD SWITCH HEAD/PARK HEADLAMP SWITCH HOT AT ALL TIMES HOT W/ ACCESSORY DELAY RELAY ENERGIZED IGNITION SWITCH ILLUM ILLUM GND LAMPS OFF LEFT FRONT DOOR LOCK SWITCH LEFT REAR DOOR LOCK SWITCH LEFT STEERING WHEEL SWITCH LOGIC GND LOW BEAM LOWER MULTI-FUNCTION SWITCH MICRO - NCA WIRE OFF OVERHEAD CONSOLE PARK PARK LAMPS REQ+ RIGHT FRONT DOOR LOCK SWITCH RIGHT REAR DOOR LOCK SWITCH RIGHT STEERING WHEEL SWITCH SELECTOR LEVER ASSEMBLY STEERING COLUMN CONTROL MODULE (SCCM) SUPER CREW CAB UPPER MULTI-FUNCTION SWITCH VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE W/O SYNC WHT WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/VIO WIRE

Go to component -> Instrument illumination circuit -> BLK WIRE

blk wiring diagram (8 of 43)

BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/BLU WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/RED WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/BLU WIRE BRN/GRN WIRE CENTRAL LOCK RELAY CENTRAL UNLOCK RELAY COMPUTER DATA LINES SYSTEM DR LOCK SW DR UNLOCK SW DRIVER/ FUEL FLAP UNLOCK RELAY DRV DR FUSE 24 FUSE 3 FUSE 67 GND LOCK GND UNLOCK GRN WIRE GRN/VIO WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/YEL WIRE HOOD AJAR SWITCH HOT AT ALL TIMES KEY LOCK KEY UNLOCK LEFT FRONT DOOR LOCK SWITCH LEFT REAR DOOR LOCK SWITCH LF DR AJAR LOCK LR DR AJAR MICRO - RF DR AJAR RR DR AJAR SUPER CREW CAB TAILGATE LATCH ACTUATOR UNLOCK VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/ORG WIRE YEL WIRE YEL/GRN WIRE YEL/GRY WIRE

Go to component -> Power door locks circuit (3 of 4) -> BLK WIRE

blk wiring diagram (9 of 43)

AUTO DIMMING INTERIOR MIRROR BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/GRY WIRE BLK/VIO WIRE BLU WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE FUSE 23 HOT W/ RUN/START RELAY ENERGIZED IGN OUT LIN 4 MICRO - NCA WIRE POWER DISTRIBUTION SYSTEM REAR PARKING AID CAMERA CONNECTOR REAR VIDEO - SHIELD SYNC MODULE (APIM) (CENTER OF DASH) VIO/WHT WIRE VPWR W/O SYNC WHT WIRE WHT/GRN WIRE

Go to component -> Rear camera circuit, chassis cab -> BLK WIRE

blk wiring diagram (10 of 43)

AUTO DIMMING INTERIOR MIRROR BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/GRY WIRE BLK/VIO WIRE BLU WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE FUSE 23 HOT W/ RUN/START RELAY ENERGIZED IGN OUT LIN 4 MICRO - NCA WIRE POWER DISTRIBUTION SYSTEM REAR PARKING AID CAMERA REAR VIDEO - SHIELD SYNC MODULE (APIM) (CENTER OF DASH) VIO/WHT WIRE VPWR W/O SYNC WHT WIRE WHT/GRN WIRE

Go to component -> Rear camera circuit, super cab & super crew cab -> BLK WIRE

Page 1 of 5

1 2 3 4 5
