Computer data lines circuit for Ford Ranger II facelift (2009-2011)

10 9 19 20 HS CAN+ HS CAN- RCS CAN- RCS CAN+ 37 24 14 26 RCS CAN+ RCS CAN- HS CAN- HS CAN+ ANTI LOCK BRAKE SYSTEM (ABS) MODULE (LEFT SIDE OF ENGINE COMPT) AUDIO UNIT BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BRN WIRE DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH) FEPS FUSE 29 GRN/ORG WIRE GRY/ORG WIRE GRY/RED WIRE HOT AT ALL TIMES HS CAN+ INSTRUMENT CLUSTER (IC) LOW CURRENT BOARD MODULE (CENTER OF DASH) MS CAN + OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM) (UNDER FRONT PASSENGER'S SEAT) POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPT) RESTRAINTS CONTROL MODULE (RCM) (UNDER FRONT OF CENTER CONSOLE) SATELLITE RADIO RECEIVER (RIGHT SIDE OF DASH) SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL) VIO/ORG WIRE WHT WIRE WHT/BLU WIRE
