Ford Ranger II facelift (2009-2011) w/ power equipment Wiring diagrams
This page contains all the electrical diagrams for the component. w/ power equipment, in which he is found in the car Ford Ranger II facelift (2009-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
w/ power equipment wiring diagram (1 of 3)
A/C COMPRESSOR CLUTCH FIELD COIL
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
BATTERY
BLK WIRE
BLK/YEL WIRE
BLOWER MOTOR RELAY
BLOWER MOTOR RESISTOR
BLU WIRE
BRAKE FLUID LEVEL SWITCH
CLIMATE CONTROL ASSEMBLY
DIGITAL TRANSMISSION RANGE (TR) SENSOR
DK BLU WIRE
DRIVER SIDE MASTER DOOR WINDOW LOCK ADJUST SWITCH SWITCH
EXTERIOR REAR VIEW MIRROR SWITCH
FUEL TANK UNIT
GRY WIRE
HORN
LEFT FRONT DOOR AJAR SWITCH
LEFT FRONT FOG LAMP
LEFT FRONT PARK/TURN LAMP
LEFT FRONT SIDE LAMP
LEFT HEADLAMP
LEFT LICENSE PLATE LAMP
LEFT REVERSING LAMP
MASS AIR FLOW/ INTAKE AIR TEMPERATURE (MAF/IAT) SENSOR
NCA WIRE
PARKING BRAKE SWITCH
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM)
RIGHT FRONT FOG LAMP
RIGHT FRONT PARK/TURN LAMP
RIGHT FRONT SIDE LAMP
RIGHT HEADLAMP
RIGHT LICENSE PLATE LAMP
RIGHT REVERSING LAMP
SHIELD
SPEED CONTROL SERVO
TRAILER TOW CONNECTOR
VIO WIRE
W/ POWER EQUIPMENT
WHT WIRE
WINDSHIELD WASHER PUMP MOTOR
WINDSHIELD WIPER MOTOR
YEL WIRE
Go to component -> Ground distribution circuit (1 of 2) -> W/ POWER EQUIPMENT
w/ power equipment wiring diagram (2 of 3)
AUDIO UNIT
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
CLIMATE CONTROL ASSEMBLY
CLOCKSPRING
DOME
DOME DEFEAT
DRIVER SIDE DOOR LOCK SWITCH
FOUR WHEEL DRIVE SWITCH
FUSE
FUSE 1
GREEN
HEAD PARK
HORNS SYSTEM
HOT AT ALL TIMES
HOT AT ALL TIMES SMART JUNCTION BOX (SJB)
HOT IN RUN OR ACC
ILLUMINATION
ILLUMINATION (6 BULBS)
ILLUMINATION DIMMER
INSTRUMENT CLUSTER
LOW CURRENT BOARD SENSE
MAIN LIGHT SWITCH
MICRO- PROCESSOR
OFF
OFF AUTO
PARK LAMP RELAY
PASSENGER SIDE DOOR LOCK SWITCH
PWM
RED/BLK WIRE
SENSE
SENSE GND
SET/ RESUME SWITCH
SPEED CONTROL
SPEED CONTROL ON/OFF SWITCH
TRACTION CONTROL SWITCH (TCS)
VIO/WHT WIRE
VPWR
W/ POWER EQUIPMENT
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Instrument illumination circuit -> W/ POWER EQUIPMENT
w/ power equipment wiring diagram (3 of 3)
1 2 3 4 5 6 7 8 9 10 11 12 MS CAN+
1 2 R SPKR + R SPKR -
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 GROUND
3 4 L SPKR - L SPKR +
ANT
ANTENNA
AUDIO INPUT JACK
AUDIO UNIT
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FUSE 12
FUSE 24
FUSE 6
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN RUN OR ACC
ILLUMINATION
L SPKR + R SPKR + MS CAN-
LEFT FRONT SPEAKER
LEFT REAR SPEAKER
LOW SENSE CURRENT BOARD
MS CAN + MA CAN -
NCA WIRE
R SPKR + R SPKR - L SPKR + L SPKR -
R SPKR + R SPKR - L SPKR + L SPKR - SHIELD
RED WIRE
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
SATELLITE RADIO RECEIVER (RIGHT SIDE OF DASH)
SEAT)
SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL)
VBATT SHIELD L SPKR - R SPKR -
VIO WIRE
VIO/BRN WIRE
VIO/ORG WIRE
VIO/RED WIRE
W/ POWER EQUIPMENT
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Radio circuit -> W/ POWER EQUIPMENT
