Ford Ranger II facelift (2009-2011) (rear light connector harness, near breakout Wiring diagram
This page shows the only wiring diagram for the component.(rear light connector harness, near breakout, which is found in the car Ford Ranger II facelift (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (rear light connector harness, near breakout (1 of 1)
BATTERY JUNCTION BOX (BJB) (LEFT REAR OF ENGINE COMPT)
BLK/YEL WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH (LEFT SIDE OF DASH)
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
EXCEPT STX
FUSE 17
FUSE 19
FUSE 20
FUSE 38
FUSE 42
GRN WIRE
GRY WIRE
GRY/YEL WIRE
HAZARD
HAZARD OFF
HAZARD RIGHT TURN OFF LEFT TURN RIGHT TURN OFF LEFT TURN
HIGH MOUNTED STOPLAMP
HOT AT ALL TIMES
HOT IN
INSTRUMENT CLUSTER (IC)
LEFT REAR PARK/STOP LAMP
LEFT REAR PARK/STOP TURN LAMP
LEFT TURN SIGNAL IND
MICROPROCESSOR
MULTI- FUNCTION SWITCH
OFF
RED WIRE
RIGHT LICENSE PLATE LAMP LEFT LICENSE PLATE LAMP
RIGHT REAR PARK/ STOP LAMP
RIGHT REAR PARK/STOP TURN LAMP
RIGHT TURN OFF LEFT TURN
RIGHT TURN SIGNAL IND
RUN WIRE
SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL)
STX
TRAILER TOW CONNECTOR
VIO WIRE
VIO/BRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/VIO WIRE
Go to component: -> Exterior lamps circuit (1 of 2) -> (REAR LIGHT CONNECTOR HARNESS, NEAR BREAKOUT
