Ford Ranger II facelift (2009-2011) multi-function switch 1) mist wiring diagram
This page shows the only wiring diagram for the component.multi-function switch 1) mist, which is found in the car Ford Ranger II facelift (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
multi-function switch 1) mist wiring diagram (1 of 1)
BATTERY JUNCTION
BLK WIRE
BLU WIRE
BRN WIRE
ELECTRONICS
FRONT WASH 2) OFF 3) INT 1 4) INT 2 5) INT 3 6) INT 4 7) INT 5 8) LOW 9) HIGH
FRONT WASHER PUMP RELAY
FRONT WIPER
FUSE
FUSE BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HALL SENSOR
HI/LO WIPER RELAY
HOT AT ALL TIMES
HOT IN RUN OR ACC
MULTI-FUNCTION SWITCH 1) MIST
ORG/ WIRE
PARK SENSE
RED WIRE
RELAY
RUN/ PARK
RUN/ PARK WIPER
SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL)
VIO WIRE
WHT WIRE
WINDSHIELD WASHER PUMP MOTOR (RIGHT SIDE OF ENGINE COMPT)
WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT)
YEL WIRE
Go to component -> Wiper/washer circuit -> MULTI-FUNCTION SWITCH 1) MIST
