Ford Ranger II facelift (2009-2011) door ajar trans neu Wiring diagrams

This page contains all the electrical diagrams for the component. door ajar trans neu, in which he is found in the car Ford Ranger II facelift (2009-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram door ajar trans neu (1 of 2)

Wiring diagram door ajar trans neu for Ford Ranger II facelift (2009-2011)

Get access

BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DIGITAL TRANSMISSION RANGE (DTR) SENSOR (A/T) (LEFT SIDE OF TRANSMISSION) DOOR AJAR IND DOOR AJAR TRANS NEU FOUR WHEEL DRIVE SWITCH FUSE 10 FUSE 27 FUSE 28 FUSE 33 GEAR MOTOR ENCODER ASSEMBLY (UNDER VEHICLE, NEAR TRANSMISSION) GND MTR CW MTR CCW VBATT VBATT GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRY/ORG WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT IN RUN OR START ILLUM IND INSTRUMENT CLUSTER (IC) LOW CURRENT BOARD MICRO- PROCESSOR MODULE (CENTER OF DASH) NEU TOW IND NEUTRAL TOW INDICATOR OFF ORG/ WIRE POS RTN RED WIRE SEAT) SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL) VIO WIRE VIO/GRN WIRE VIO/ORG WIRE VIO/WHT WIRE VPWR HS CAN- HS CAN+ WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/ORG WIRE YEL WIRE YEL/ORG WIRE

Go to component: -> 2.3l, 4wd circuit -> DOOR AJAR TRANS NEU

Wiring diagram door ajar trans neu (2 of 2)

Wiring diagram door ajar trans neu for Ford Ranger II facelift (2009-2011)

Get access

BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DIGITAL TRANSMISSION RANGE (DTR) SENSOR (A/T) (LEFT SIDE OF TRANSMISSION) DOOR AJAR IND DOOR AJAR TRANS NEU FOUR WHEEL DRIVE SWITCH FUSE 10 FUSE 27 FUSE 28 FUSE 33 GEAR MOTOR ENCODER ASSEMBLY (UNDER VEHICLE, NEAR TRANSMISSION) GND MTR CW MTR CCW VBATT VBATT GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRY/ORG WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT IN RUN OR START ILLUM IND INSTRUMENT CLUSTER (IC) LOW CURRENT BOARD MICRO- PROCESSOR MODULE (CENTER OF DASH) NEU TOW IND NEUTRAL TOW INDICATOR OFF ORG/ WIRE POS RTN RED WIRE SEAT) SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL) VIO WIRE VIO/GRN WIRE VIO/ORG WIRE VIO/WHT WIRE VPWR HS CAN- HS CAN+ WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/ORG WIRE YEL WIRE YEL/ORG WIRE

Go to component: -> 4.0l, 4wd circuit -> DOOR AJAR TRANS NEU
