Ford Ranger II facelift (2009-2011) case ground Wiring diagram

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/LT BLU WIRE CASE GROUND CLOCKSPRING (IN STEERING WHEEL) COMPUTER DATA LINES SYSTEM DRIVER AIR BAG UNIT (IN STEERING WHEEL) DRIVER FRONT DOOR SIDE IMPACT SENSOR (IN DRIVER'S DOOR) DRIVER SAFETY BELT BUCKLE SWITCH (DRIVER'S SEAT BELT BUCKLE ASSEMBLY) DRIVER SEAT POSITION SENSOR (UNDER DRIVER'S SEAT) FUSE 8 GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRY WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT IN RUN OR START LEFT FRONT IMPACT SEVERITY SENSOR (LEFT FRONT OF ENGINE COMPT) LT BLU WIRE ORG/ WIRE PAD LAMP PASSENGER FRONT DOOR SIDE IMPACT SENSOR (IN FRONT PASSENGER'S DOOR) RCS CAN- RCS CAN+ PASS SIDE SENS RTN PASS SIDE SENS FEED RED WIRE RED/ORG WIRE RED/WHT WIRE RESTRAINTS CONTROL MODULE (RCM) (UNDER FRONT OF CENTER CONSOLE) RIGHT FRONT IMPACT SEVERITY SENSOR (RIGHT FRONT OF ENGINE COMPT) RUN/START SENSE RTN RTN SENSE SHORTING BAR SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL) SOLID STATE STAGE 1 STAGE 2 VIO WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE WHT WIRE WHT/BLU WIRE WHT/ORG WIRE YEL WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/WHT WIRE
