Ford Ranger II facelift (2009-2011) a/c compressor clutch field coil Wiring diagram
This page shows the only wiring diagram for the component.a/c compressor clutch field coil, which is found in the car Ford Ranger II facelift (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/c compressor clutch field coil (1 of 1)
A/C COMPRESSOR CLUTCH FIELD COIL
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
BATTERY
BLK WIRE
BLK/YEL WIRE
BLOWER MOTOR RELAY
BLOWER MOTOR RESISTOR
BLU WIRE
BRAKE FLUID LEVEL SWITCH
CLIMATE CONTROL ASSEMBLY
DIGITAL TRANSMISSION RANGE (TR) SENSOR
DK BLU WIRE
DRIVER SIDE MASTER DOOR WINDOW LOCK ADJUST SWITCH SWITCH
EXTERIOR REAR VIEW MIRROR SWITCH
FUEL TANK UNIT
GRY WIRE
HORN
LEFT FRONT DOOR AJAR SWITCH
LEFT FRONT FOG LAMP
LEFT FRONT PARK/TURN LAMP
LEFT FRONT SIDE LAMP
LEFT HEADLAMP
LEFT LICENSE PLATE LAMP
LEFT REVERSING LAMP
MASS AIR FLOW/ INTAKE AIR TEMPERATURE (MAF/IAT) SENSOR
NCA WIRE
PARKING BRAKE SWITCH
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM)
RIGHT FRONT FOG LAMP
RIGHT FRONT PARK/TURN LAMP
RIGHT FRONT SIDE LAMP
RIGHT HEADLAMP
RIGHT LICENSE PLATE LAMP
RIGHT REVERSING LAMP
SHIELD
SPEED CONTROL SERVO
TRAILER TOW CONNECTOR
VIO WIRE
W/ POWER EQUIPMENT
WHT WIRE
WINDSHIELD WASHER PUMP MOTOR
WINDSHIELD WIPER MOTOR
YEL WIRE
Go to component: -> Ground distribution circuit (1 of 2) -> A/C COMPRESSOR CLUTCH FIELD COIL
