Courtesy lamps circuit for Ford Ranger II (2006-2009)
Courtesy lamps circuit
BLK WIRE
BLU WIRE
BRN WIRE
CONTROL GND
DOME DEFEAT DOME
DRIVER SIDE REAR DOOR AJAR SWITCH (4 DOOR)
FRONT INTERIOR/ MAP LAMPS ASSEMBLY
FUSE 11
FUSE 13
GRN WIRE
HOT AT ALL TIMES
ILLUMINATION DIMMER
INSTRUMENT CLUSTER SYSTEM
INTERIOR LAMP RELAY
LEFT FRONT DOOR AJAR SWITCH (REAR OF DRIVER'S DOOR)
LOW CURRENT BOARD
OFF
ORG/ WIRE
PASSENGER SIDE REAR DOOR AJAR SWITCH (4 DOOR) (BOTTOM REAR OF RIGHT REAR DOOR)
RIGHT FRONT DOOR AJAR SWITCH (REAR OF PASSENGER'S DOOR)
SENSE
SENSE SENSE
VBATT
VIO WIRE
WHT WIRE
YEL WIRE
