Car Wiring Diagrams for Ground distribution circuit for Ford Ranger II (2006-2009)

A/C CLUTCH FIELD COIL ABS CONTROL MODULE BATTERY BLK WIRE BLK/YEL WIRE BLOWER MOTOR RELAY BLU WIRE BRAKE FLUID LEVEL SWITCH DRIVER SIDE DOOR LOCK SWITCH EXTERIOR REAR VIEW MIRROR SWITCH MASTER WINDOW ADJUST FRONT FUNCTION SELECTOR SWITCH ASSEMBLY FRONT HEATED BLOWER MOTOR RESISTOR FUEL TANK UNIT GRY WIRE HORN LEFT FRONT DOOR AJAR SWITCH LEFT FRONT FOG LAMP LEFT FRONT PARK/TURN LAMP LEFT FRONT SIDE LAMP LEFT HEADLAMP LEFT LICENSE PLATE LAMP LEFT REAR PARK/STOP TURN LAMP LEFT REVERSING LAMP MASS AIR FLOW/ INTAKE AIR TEMPERATURE (MAF/IAT) SENSOR NCA WIRE PARKING BRAKE SWITCH PCM POWER RELAY POWERTRAIN CONTROL MODULE (PCM) RIGHT FRONT FOG LAMP RIGHT FRONT PARK/TURN LAMP RIGHT FRONT SIDE LAMP SPEED CONTROL SERVO RIGHT HEADLAMP RIGHT LICENSE PLATE LAMP RIGHT REAR PARK/STOP TURN LAMP RIGHT REVERSING LAMP SHIELD SWITCH TRAILER TOW CONNECTOR TRANSMISSION) DIGITAL TRANSMISSION RANGE (DTR) SENSOR VIO WIRE W/ POWER EQUIPMENT WHT WIRE WINDSHIELD WASHER PUMP MOTOR WINDSHIELD WIPER MOTOR YEL WIRE

AUDIO UNIT BLEND DOOR ACTUATOR BLK WIRE BLK/YEL WIRE BLU WIRE BRAKE PEDAL POSITION SWITCH BRAKE SHIFT INTERLOCK CLOCK- SPRING CLUTCH PEDAL POSITION SWITCH DATA LINK CONNECTOR (DLC) DOOR LOCK/UNLOCK RELAY DRIVER DOOR UNLOCK RELAY DRIVER SAFETY BELT BUCKLE SWITCH DRIVER SEAT POSITION SENSOR DRIVER SIDE REAR DOOR AJAR SWITCH EXCEPT TREMOR FOUR WHEEL DRIVE CONTROL MODULE FOUR WHEEL DRIVE SWITCH FOUR-DOOR MODEL FRONT CIGAR LIGHTER FRONT FUNCTION SELECTOR SWITCH ASSEMBLY FUEL TANK UNIT HIGH MOUNTED STOPLAMP HORN SWITCH ILLUMINATION DIMMER INDICATOR FLASHER RELAY INSTRUMENT CLUSTER LOW CURRENT BOARD LT BLU WIRE MAIN LIGHT SWITCH MULTIFUNCTION SWITCH OCCUPANT CLASSIFICATION SENSOR (OCS) MODULE PASSENGER SAFETY BELT BUCKLE SWITCH PASSENGER SIDE DOOR LOCK SWITCH RIGHT FRONT DOOR AJAR SWITCH PASSENGER SIDE REAR DOOR AJAR SWITCH PASSIVE ANTI-THEFT TRANSCEIVER POWER POINT RADIO, AMPLIFIER SPEED CONTROL ON/OFF SWITCH SPEED CONTROL SET/RESUME SWITCH SUBWOOFER AMPLIFIER WHT WIRE YEL WIRE
