Ford Ranger II (2006-2009) Heater circuit

BATTERY JUNCTION BOX (BJB) (LEFT REAR SIDE OF ENGINE COMPT) BLEND DOOR ACTUATOR (BEHIND RIGHT SIDE OF DASH) BLK WIRE BLK/GRY WIRE BLK/YEL WIRE BLOWER MOTOR RELAY BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE CONTROL CIRCUIT DEFROST DEF/FLOOR FLOOR DEFROST MAX FRONT FUNCTION SELECTOR SWITCH ASSEMBLY FUSE 13 FUSE 27 GRN WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/ORG WIRE HIGH MEDIUM HIGH HOT AT ALL TIMES HOT IN RUN ILLUMINATION MAX MEDIUM LOW LOW NORMAL VENT FLOOR/VENT OFF OFF FLOOR VENT A/C MIX RED WIRE SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL) TEMPERATURE POTENTIOMETER THERMAL LIMITER VIO WIRE VIO/GRY WIRE VIO/ORG WIRE YEL WIRE YEL/GRN WIRE
