Ford Ranger II (2006-2009) smart junction Wiring diagram

This page shows the only wiring diagram for the component.smart junction, which is found in the car Ford Ranger II (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram smart junction (1 of 1)

Wiring diagram smart junction for Ford Ranger II (2006-2009)

Get access

BLK/BLU WIRE BLU WIRE BRN WIRE BRN/RED WIRE DOWN DOWN UP EXTERIOR REAR VIEW MIRROR SWITCH FUSE BOX (SJB) (RIGHT KICK PANEL) GRN WIRE GRY WIRE GRY/ORG WIRE HOT AT ALL TIMES LEFT EXTERIOR REAR VIEW MIRROR (FRONT OF DRIVER`S DOOR) LEFT MIRROR LEFT RIGHT LEFT UP LEFT/RIGHT NCA WIRE ORG/ WIRE RIGHT RIGHT EXTERIOR REAR VIEW MIRROR (FRONT OF PASSENGER`S DOOR) RIGHT MIRROR SELECT SMART JUNCTION UP/DOWN VIO WIRE VIO/ORG WIRE YEL WIRE YEL/VIO WIRE

Go to component: -> Power mirrors circuit -> SMART JUNCTION
