Ford Ranger II (2006-2009) left head- lamp lo hi Wiring diagram
This page shows the only wiring diagram for the component.left head- lamp lo hi, which is found in the car Ford Ranger II (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left head- lamp lo hi (1 of 1)
2.3L EXCEPT 2.3L
AUTO OFF PARK
BATTERY JUNCTION BOX (BJB) (LEFT REAR SIDE OF ENGINE COMPT)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU/WHT WIRE
BREAKOUT)
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN (-) CAN (+)
COMPUTER DATA LINES SYSTEM
CTRL SENSE
FLASH TO PASS
FOG
FOG LAMP RELAY
FUSE 14
FUSE 23
FUSE 31
FUSE 4 FUSE 3
GRN/BRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/VIO WIRE
HEAD
HIGH BEAM IND
HOT AT (RIGHT KICK PANEL) SMART JUNCTION BOX (SJB) ALL TIMES
HOT AT ALL TIMES
INSTRUMENT CLUSTER
JUNCTION HARNESS, NEAR BREAKOUT
LEFT HEAD- LAMP LO HI
LOW CURRENT BOARD
LOW HIGH
MAIN LIGHT SWITCH
MICROPROCESSOR
MULTI- FUNCTION SWITCH
OFF
PARKING BRAKE SWITCH (BELOW LEFT SIDE OF DASH, ON PARK BRAKE ASSEMBLY)
PWM
RIGHT FRONT FOG LAMP LEFT FRONT FOG LAMP
RIGHT HEAD- LAMP LO HI
SENSE
VBATT DRL DRIVER
VBATT SENSE
VIO WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
Go to component: -> Headlights circuit, with drl -> LEFT HEAD- LAMP LO HI
