Ford Ranger II (2006-2009) (in dash panel to headlight junction harness, Wiring diagram
This page shows the only wiring diagram for the component.(in dash panel to headlight junction harness,, which is found in the car Ford Ranger II (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (in dash panel to headlight junction harness, (1 of 1)
A/C CLUTCH FIELD COIL
ABS CONTROL MODULE
BATTERY
BLK WIRE
BLK/YEL WIRE
BLOWER MOTOR RELAY
BLU WIRE
BRAKE FLUID LEVEL SWITCH
DRIVER SIDE DOOR LOCK SWITCH
EXTERIOR REAR VIEW MIRROR SWITCH MASTER WINDOW ADJUST
FRONT FUNCTION SELECTOR SWITCH ASSEMBLY
FRONT HEATED BLOWER MOTOR RESISTOR
FUEL TANK UNIT
GRY WIRE
HORN
LEFT FRONT DOOR AJAR SWITCH
LEFT FRONT FOG LAMP
LEFT FRONT PARK/TURN LAMP
LEFT FRONT SIDE LAMP
LEFT HEADLAMP
LEFT LICENSE PLATE LAMP
LEFT REAR PARK/STOP TURN LAMP
LEFT REVERSING LAMP
MASS AIR FLOW/ INTAKE AIR TEMPERATURE (MAF/IAT) SENSOR
NCA WIRE
PARKING BRAKE SWITCH
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM)
RIGHT FRONT FOG LAMP
RIGHT FRONT PARK/TURN LAMP
RIGHT FRONT SIDE LAMP SPEED CONTROL SERVO
RIGHT HEADLAMP
RIGHT LICENSE PLATE LAMP
RIGHT REAR PARK/STOP TURN LAMP
RIGHT REVERSING LAMP
SHIELD
SWITCH
TRAILER TOW CONNECTOR
TRANSMISSION) DIGITAL TRANSMISSION RANGE (DTR) SENSOR
VIO WIRE
W/ POWER EQUIPMENT
WHT WIRE
WINDSHIELD WASHER PUMP MOTOR
WINDSHIELD WIPER MOTOR
YEL WIRE
Go to component: -> Ground distribution circuit (1 of 2) -> (IN DASH PANEL TO HEADLIGHT JUNCTION HARNESS,
