Ford Ranger II (2006-2009) fuse 16 Wiring diagram
This page shows the only wiring diagram for the component.fuse 16, which is found in the car Ford Ranger II (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 16 (1 of 1)
ACCESSORY RELAY
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/GRY WIRE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
DOWN
FUSE 11
FUSE 16
GRN/ORG WIRE
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LOW CURRENT BOARD
MASTER WINDOW ADJUST SWITCH
OFF DOWN
ONE-TOUCH WINDOW RELAY
ORG/ WIRE
PASSENGER
PASSENGER SIDE FRONT POWER WINDOW MOTOR (CENTER OF PASSENGER'S DOOR)
PASSENGER SIDE WINDOW ADJUST SWITCH
PTC CIRCUIT BREAKER
RESISTOR
SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL)
UP REST
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Power windows circuit -> FUSE 16
