Car Wiring Diagrams for Power distribution circuit for Ford Ranger I (1998-2006)

A/C CLUTCH RELAY ABS CONTROL MODULE ACCESSORY RELAY FUSE 5 FUSE 6 AUDIO UNIT BATTERY BATTERY JUNCTION BOX (BJB) (AT LEFT REAR SIDE OF ENGINE COMPARTMENT) BATTERY JUNCTION BOX (BJB) (AT LEFT REAR SIDE OF ENGINE COMPT) BLK WIRE BLOWER MOTOR RELAY BRN WIRE DK BLU WIRE DK GRN WIRE DOOR LOCK/ UNLOCK RELAY DRIVER DOOR UNLOCK RELAY DRL DRIVER ENGINE COOLING FAN RELAY FOG LAMP RELAY FOUR WHEEL DRIVE CONTROL MODULE FUEL PUMP RELAY FUSE 10 FUSE 11 FUSE 13 FUSE 17 FUSE 15 FUSE 1 FUSE 2 FUSE 19 FUSE 21 FUSE 23 FUSE 25 FUSE 27 FUSE 3 FUSE 30 FUSE 23 FUSE 31 FUSE 31 FUSE 24 FUSE 34 RADIO AMPLIFIER (TREMOR) FUSE 35 FUSE 5 FUSE 7 FUSE 8 FUSE 9 FUSIBLE LINK A (12 GA- FUSIBLE LINK B (12 GA- FUSIBLE LINK C GENERATOR GRN WIRE GRY WIRE IGNITION SWITCH INSTRUMENT CLUSTER PASSENGER AIR BAG DEACTIVATION (PAD) SWITCH LOCK OFF LOW CURRENT BOARD LT BLU WIRE LT GRN WIRE MAIN LIGHT SWITCH MULTI- FUNCTION SWITCH EXTERIOR REAR VIEW MIRROR SWITCH ORG/ WIRE PARK LAMP RELAY PCM POWER RELAY PNK STARTER MOTOR WIRE PNK WIRE POWER POINT POWERTRAIN CONTROL MODULE (PCM) RED WIRE RESTRAINTS CONTROL MODULE RUN WIRE SMART JUNCTION BOX (SJB) (BEHIND RIGHT SIDE OF DASH) STARTER RELAY TO FUSE 17 (DIAGRAM 2 OF 2) TO FUSE 22 (DIAGRAM 2 OF 2) TO FUSE 27 (DIAGRAM 2 OF 2) TO FUSE 33 (DIAGRAM 2 OF 2) TO PTC CIRCUIT BREAKER (DIAGRAM 2 OF 2) VIO WIRE WHT WIRE WINDSHIELD WASHER RELAY WINDSHIELD WIPER MOTOR WIPER HIGH/LOW RELAY WIPER RUN/PARK RELAY YEL WIRE

A/T ABS CONTROL MODULE ACCESSORY RELAY HORN RELAY AUDIO UNIT BATTERY JUNCTION BOX (BJB) (AT LEFT REAR SIDE OF ENGINE COMPARTMENT) BLEND DOOR ACTUATOR BLK WIRE BRAKE PEDAL POSITION SWITCH BRAKE SHIFT INTERLOCK BRN WIRE CLUTCH PEDAL POSITION SWITCH DATA LINK CONNECTOR (DLC) DEACTIVATOR SWITCH DIGITAL TRANSMISSION RANGE (DTR) SENSOR DIGITAL TRANSMISSION RANGE (DTR) SENSOR REVERSING LAMPS SWITCH DK BLU WIRE DK GRN WIRE FOUR WHEEL DRIVE CONTROL MODULE FOUR-WHEEL DRIVE CONTROL MODULE (M/T, 3.0L, 4.0L) FROM FUSE 3 (DIAGRAM 1 OF 2) FROM FUSE 5 (DIAGRAM 1 OF 2) FROM FUSE 10 (DIAGRAM 1 OF 2) PTC CIRCUIT BREAKER FROM IGNITION SWITCH (DIAGRAM 1 OF 2) FRONT CIGAR LIGHTER FRONT FUNCTION SELECTOR SWITCH ASSEMBLY FUSE 11 FUSE 12 FUSE 17 FUSE 16 FUSE 13 FUSE 19 FUSE 20 FUSE 21 FUSE 22 FUSE 26 FUSE 27 FUSE 28 FUSE 29 FUSE 32 FUSE 33 GRY WIRE INDICATOR FLASHER RELAY INDICATOR FLASHER RELAY SUBWOOFER AMPLIFIER (W/ AUDIOPHILE SOUND SYSTEM) INSTRUMENT CLUSTER INTERIOR LAMP/BATTERY SAVER RELAY LOW CURRENT BOARD LT BLU WIRE LT GRN WIRE M/T M/T A/T NCA WIRE OFF ORG/ WIRE PASSIVE ANTI-THEFT TRANSCEIVER PCM POWER DIODE PCM POWER RELAY PNK (OR PNK) WIRE PNK WIRE RED WIRE SMART JUNCTION BOX (SJB) (BEHIND RIGHT SIDE OF DASH) TRANSMISSION CONTROL SWITCH VIO WIRE WHT WIRE YEL WIRE
