Ford Ranger I (1998-2006) motor 5 bpp switch Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 B+ B+ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 SIG RETURN GROUND A/T ANTI-LOCK BRAKES SYSTEM AUDIO UNIT BATTERY JUNCTION BOX (LEFT REAR SIDE OF ENGINE COMPT) FUSE 27 BLK WIRE BLK/WHT WIRE BRAKE PEDAL POSITION SWITCH (BEHIND LEFT SIDE OF DASH, ON BRAKE PEDAL SUPPORT) BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR (AT BOTTOM OF STEERING COLUMN) DK GRN WIRE DK GRN/LT GRN WIRE FOUR WHEEL DRIVE SWITCH FOUR-WHEEL DRIVE CONTROL MODULE (BEHIND LEFT CENTER OF DASH) FUNCTION SELECT SWITCH ASSEMBLY, BLEND DOOR ACTUATOR FUSE 10 FUSE 21 FUSE 27 FUSE 28 FUSE 32 FUSE 7 GEARMOTOR ENCODER ASSEMBLY GROUND TRANSFER CASE IGN (RUN) GRY WIRE GRY/BLK WIRE GRY/YEL WIRE HEAD HOT AT ALL TIMES HOT IN HOT IN RUN OR START IGN (ST/RUN) ILLUM INSTRUMENT CLUSTER INTERIOR LIGHTS SYSTEM (DIMMER) ISO BUS LT BLU/BLK WIRE LT BLU/RED WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/WHT WIRE M/T MAIN LIGHT SWITCH MOTOR 1 MOTOR 3 MOTOR 4 NEUTRAL SENS TRANSFER CASE MOTOR 5 BPP SWITCH OFF OFF PARK ORG/ WIRE ORG/BLK WIRE ORG/WHT WIRE POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) RED WIRE RED/LT GRN WIRE RED/WHT WIRE RED/YEL WIRE RUN WIRE SMART JUNCTION BOX (BEHIND RIGHT SIDE OF DASH) SPEED CONTROL SERVO, BODY COMPUTER VIO/YEL WIRE VSS INPUT MOTOR 2 WHT WIRE WHT/LT BLU WIRE YEL WIRE YEL/LT BLU WIRE YEL/WHT WIRE
