Ford Ranger I (1998-2006) medium high medium low Wiring diagram
This page shows the only wiring diagram for the component.medium high medium low, which is found in the car Ford Ranger I (1998-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram medium high medium low (1 of 1)
BATTERY JUNCTION BOX (BJB) (AT LEFT REAR SIDE OF ENGINE COMPARTMENT)
BLEND DOOR ACTUATOR (BEHIND RIGHT SIDE OF DASH)
BLK WIRE
BLOWER MOTOR RELAY
BLOWER MOTOR SWITCH
BRN WIRE
FRONT FUNCTION SELECTOR SWITCH ASSEMBLY
FUSE 13
FUSE 27
GRY WIRE
GRY/YEL WIRE
HEATER BLOWER MOTOR (RIGHT REAR OF ENGINE COMPARTMENT, ON FIREWALL)
HOT AT ALL TIMES
HOT IN RUN
ILLUMINATION
LOW HIGH
LT BLU WIRE
LT GRN WIRE
MEDIUM HIGH MEDIUM LOW
MICROPROCESSOR
MODE SWITCH
OFF VENT FLOOR MIX NORMAL DEFROST MAX
ORG/ WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPT, THROUGH FIREWALL)
RED WIRE
RED/LT GRN WIRE
RED/WHT WIRE
SMART JUNCTION BOX (SJB) (BEHIND RIGHT SIDE OF DASH)
TEMPERATURE CONTROL POTENTIOMETER
VIO WIRE
WHT WIRE
YEL WIRE
YEL/LT GRN WIRE
Go to component -> Heater circuit -> MEDIUM HIGH MEDIUM LOW
