Ford Ranger I (1998-2006) driver side rear door ajar switch indicator flasher relay Wiring diagram
This page shows the only wiring diagram for the component.driver side rear door ajar switch indicator flasher relay, which is found in the car Ford Ranger I (1998-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side rear door ajar switch indicator flasher relay (1 of 1)
AT BREAKOUT FOR POWERTRAIN CONTROL MODULE)
AUDIO UNIT
BLK WIRE
BRAKE PEDAL POSITION SWITCH
BRAKE SHIFT INTERLOCK
DATA LINK CONNECTOR (DLC)
DOOR LOCK/UNLOCK RELAY
DRIVER DOOR UNLOCK RELAY ACCESSORY RELAY
DRIVER SAFETY BELT RETRACTOR PRETENSIONER BLEND DOOR ACTUATOR
DRIVER SIDE REAR DOOR AJAR SWITCH INDICATOR FLASHER RELAY
FOG LAMP SWITCH
FOUR WHEEL DRIVE CONTROL MODULE
FOUR WHEEL DRIVE SWITCH
FOUR-DOOR
FRONT CIGAR LIGHTER
FRONT FUNCTION SELECTOR SWITCH ASSEMBLY
FRONT HEATER BLOWER MOTOR RESISTOR
HIGH MOUNTED STOP LAMP
HORN
INSTRUMENT CLUSTER
LT GRN WIRE
MAIN LIGHT SWITCH
MUTLIFUNCTION SWITCH
NCA WIRE
PASSENGER SIDE DOOR LOCK SWITCH RIGHT FRONT DOOR AJAR SWITCH
PASSENGER SIDE REAR DOOR AJAR SWITCH
POWER POINT
POWERTRAIN CONTROL MODULE (PCM)
RADIO, AMPLIFIER
RIGHT FRONT FOG LAMP
RIGHT FRONT PARK/TURN LAMP
RIGHT FRONT SIDE LAMP
RIGHT HEADLAMP
SHIELD
SPEED CONTROL SERVO
W/ POWER EQUIPMENT
WINDOW MOTOR
WINDSHIELD WASHER PUMP MOTOR
Go to component: -> Ground distribution circuit (2 of 2) -> DRIVER SIDE REAR DOOR AJAR SWITCH INDICATOR FLASHER RELAY
