Ford Ranger I (1998-2006) cht sensor canister vent vss + a/c clutch rly Wiring diagram

A/C SYSTEM A/T AUTOMATIC TRANSMISSION BATTERY JUNCTION BOX (LEFT REAR OF ENGINE COMPT) FUSE 21 BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRAKE PEDAL POSITION SWITCH (BPP) BRN WIRE BRN/LT BLU WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE CAMSHAFT POSITION (CMP) SENSOR (ON REAR OF ENGINE) CHT SENSOR CANISTER VENT VSS + A/C CLUTCH RLY DK BLU/ORG WIRE DK BLU/YEL WIRE DK GRN/WHT WIRE ELECTRONIC PRESSURE CONTROL (EPC) SOLENOID FUEL TANK PRESS MAP SENS TR SENSOR FUSE 32 GRY/BLK WIRE GRY/LT BLU WIRE GRY/ORG WIRE GRY/RED WIRE GRY/WHT WIRE HEATED OXYGEN HOT AT ALL TIMES IDLE AIR CONTROL (IAC) VALVE (TOP RIGHT OF ENGINE) ISS SENS LT BLU WIRE LT BLU/ORG WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE M/T MAF SENSOR TPS IN REF VOLTAGE SIG RETURN BPP SW ORG/BLK WIRE ORG/YEL WIRE PCM RLY POWER EGR STEP MOTOR EGR STEP MOTOR FUEL INJ 3 FUEL INJ 1 GND GND PCM RLY POWER EGR STEP MOTOR EGR STEP MOTOR FUEL INJ 4 FUEL INJ 2 PNK/BLK WIRE PNK/YEL WIRE POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPT, THROUGH FIREWALL) RED WIRE RED/LT GRN WIRE RED/PNK WIRE RED/WHT WIRE SHIFT SOLENOIDS SMART JUNCTION BOX (BEHIND RIGHT SIDE OF DASH) TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/RED WIRE TORQUE CONVERTER CLUTCH (TCC) SOLENOID TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR TURBINE SHAFT SPEED SENSOR (TSS) VIO/ORG WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/YEL WIRE YEL/LT GRN WIRE YEL/RED WIRE
