Car Wiring Diagrams for Base radio for Ford Probe II (1992-1997)

8 7 6 5 4 3 2 1 POWER (B+) ILLUM IGNITION ILLUM BLK/BLU WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND RADIO ON AMP MUTE HOT AT ALL TIMES HOT IN ACCY OR RUN INTERIOR FUSE PANEL (BEHIND LEFT SIDE OF DASH) LEFT FRONT DOOR SPEAKER LEFT REAR SPEAKER LT GRN WIRE LT GRN/YEL WIRE ORG/ WIRE POWER ANTENNA SYSTEM (1994-95 ONLY) RADIO RADIO FUSE FUSE 4 RED/GRN WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR SPEAKER ROOM FUSE FUSE 2
