Ford Probe II (1992-1997) wind- shield wiper motor Wiring diagrams

This page contains all the electrical diagrams for the component. wind- shield wiper motor, in which he is found in the car Ford Probe II (1992-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram wind- shield wiper motor (1 of 2)

Wiring diagram wind- shield wiper motor for Ford Probe II (1992-1997) (1 of 2)

Get access

BLK WIRE BLU WIRE COMBINATION SWITCH GROUND HOT IN RUN INTER- VAL RELAY INTERIOR FUSE PANEL MIST OFF LO OFF ON OFF LO ORG/ WIRE PARK RED WIRE RUN WIRE SOLID STATE WASHER SWITCH WHT WIRE WIND- SHIELD WIPER MOTOR WINDSHIELD WASHER PUMP MOTOR WIPER FUSE WIPER SWITCH

Go to component -> 2-speed wiper/washer circuit -> WIND- SHIELD WIPER MOTOR

Wiring diagram wind- shield wiper motor (2 of 2)

Wiring diagram wind- shield wiper motor for Ford Probe II (1992-1997) (2 of 2)

Get access

BLK WIRE BLU WIRE COMBINATION SWITCH GROUND HOT IN RUN INT ON OFF LO INTER- VAL RELAY SOLID STATE INTERIOR FUSE PANEL INTERVAL RHEOSTAT NCA WIRE ORG/ WIRE PARK RED WIRE RUN WIRE WASHER SWITCH OFF WHT WIRE WIND- SHIELD WIPER MOTOR WINDSHIELD WASHER MOTOR WIPER FUSE WIPER SWITCH OFF MIST LO INT

Go to component -> Interval wiper/washer circuit -> WIND- SHIELD WIPER MOTOR
