Ford Probe II (1992-1997) turn lamp marker lamp Wiring diagram
This page shows the only wiring diagram for the component.turn lamp marker lamp, which is found in the car Ford Probe II (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn lamp marker lamp (1 of 1)
2.5L 2.0L
2.5L ONLY
A/T
BACKUP LAMP
BACKUP LAMP SWITCH
BLK WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BRAKE ON/OFF SWITCH
BRN WIRE
CENTRAL PROCESSING UNIT
CENTRAL PROCESSING UNIT INTERIOR LIGHTS
COMBINATION SWITCH
ENGINE COMPT. FUSE BOX
FLASHER MODULE (BEHIND LEFT SIDE OF I/P, LEFT OF STEERING COLUMN)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
HAZARD FUSE
HAZARD SWITCH
HI MOUNT STOP LAMP
HOT AT ALL TIMES
HOT IN START OR RUN
INSTRUMENT CLUSTER
INTERIOR FUSE PANEL
INTERIOR FUSE PANEL STOP FUSE
JOINT CONNECTOR
KEYLESS ENTRY MODULE
LEFT FRONT COMBINATION LAMP
LEFT REAR COMBINATION LAMP
LEFT TURN IND
LEFT TURN RELAY
LICENSE PLATE LAMPS
M/T
MAIN LAMP SWITCH
MARKER LAMP
MARKER LAMP TURN LAMP
METER FUSE
NCA WIRE
OFF HEAD PARK
ORG/ WIRE
PARK LAMP
PARK LAMP MARKER LAMP
PARK LAMP RELAY (IN ENGINE COMPT FUSE BOX)
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT FRONT COMBINATION LAMP
RIGHT REAR COMBINATION LAMP
RIGHT TURN IND
RIGHT TURN RELAY
SOLID STATE
STOP LAMP
TAIL FUSE
TRANSAXLE CONTROL MODULE
TRANSMISSION RANGE (TR) SENSOR
TURN FUSE
TURN LAMP
TURN LAMP MARKER LAMP
TURN SIGNAL SWITCH
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WITH ANTI- THEFT
WITH KEYLESS ENTRY
YEL WIRE
YEL/RED WIRE
Go to component -> Exterior light circuit -> TURN LAMP MARKER LAMP
