Ford Probe II (1992-1997) park/neutral position sw wiring diagram
This page shows the only wiring diagram for the component.park/neutral position sw, which is found in the car Ford Probe II (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
park/neutral position sw wiring diagram (1 of 1)
ASSEMBLY
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/PNK (OR BLK/ORG) WIRE
BLK/PNK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN/YEL WIRE
CLUTCH PEDAL POSITION SW (ON CLUTCH PEDAL SUPPORT BRACKET)
DATA LINK CONNECTOR (DLC) (ON LEFT
ENGINE COOLANT TEMP SENSOR (ECT) (TOP LEFT SIDE OF ENGINE)
ENGINE FUSE PANEL
F/P INJ FUSE BOX
FRONT FENDER APRON)
FUEL PUMP MODULE (INSIDE FUEL
FUEL PUMP RELAY (ENGINE COMPARTMENT FUSE BOX)
FUEL TACHO CUTOUT METER INDICATOR
GRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES SW
HOT IN
IGNITION
INERTIA FUEL SHUTOFF SW (BEHIND RIGHT WHEELWELL)
INSTRUMENT CLUSTER
INTAKE AIR TEMP (IAT) (LEFT SIDE OF AIR CLEANER
INTERIOR
INTERIOR FUSE PANEL
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/WHT WIRE
LT GRN/YEL WIRE
MAL/ FUNCTION INDICATOR
METER
NCA WIRE
OFF
OR RUN
ORG/GRN WIRE
PARK/NEUTRAL POSITION SW
PCM POWER RELAY (ENGINE COMPARTMENT FUSE BOX)
POWER STEERING PRESSURE SW
RUN WIRE
TANK)
THROTTLE POSITION SW (ON THROTTLE BODY)
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WHT/YEL WIRE
WHT/YEL WIRE
YEL/BLU WIRE
Go to component -> Wiring diagram engine performance 2.0ls, m/t (2 of 2) -> PARK/NEUTRAL POSITION SW
