Ford Probe II (1992-1997) left headlamp retractor Wiring diagrams
This page contains all the electrical diagrams for the component. left headlamp retractor, in which he is found in the car Ford Probe II (1992-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left headlamp retractor (1 of 2)
15 42 (2.5L) (2.0L)
2.5L
ANTI-THEFT SYSTEM
BLK WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE IND
CENTRAL PROCESSING UNIT (BEHIND LEFT SIDE OF INST PANEL, NEAR FUSE PANEL)
COMBINATION SWITCH
DAYTIME RUNNING LAMPS (DRL) MODULE (LOWER LEFT FRONT OF ENGINE COMPT)
DOWN
DRL DISABLE
ENGINE COMPARTMENT FUSE BOX
FOG LAMP RELAY (IN ENGINE COMPT FUSE BOX)
FOG LAMP SWITCH
FOG LTS ENABLE
GRN WIRE
GROUND
HEAD FUSE
HEADLAMP RELAY (LEFT SIDE OF ENGINE COMPT, IN ENGINE COMPT FUSE BOX)
HEADLAMP RETRACTOR CONTROL
HEADLAMP RETRACTOR TEST CONNECTOR
HEADLTS ON INPUT
HI BEAM INDICATOR
HI BEAMS INPUT
HI LO HI LEFT HEADLIGHT
HOT AT ALL TIMES
HOT IN ACCY OR RUN INTERIOR FUSE PANEL AIR COND FUSE
IGNITION POWER
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
LEFT FOG LIGHT
LEFT HEADLAMP RETRACTOR
LO RIGHT HEADLIGHT
MAIN LIGHT SWITCH
NCA WIRE
ON INDIC- ATOR
ON OFF
ORG/ WIRE
ORG/BLK WIRE
PARK HEAD OFF
PARK SWITCH SWITCH (ON TOP OF PARK BRAKE SUPPORT)
POWER
POWERTRAIN CONTROL MODULE (BELOW FRONT OF CENTER CONSOLE)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RETRA FUSE
RIGHT FOG LIGHT
RIGHT HEADLAMP RETRACTOR
TO DIMMER PASS LO HI
W/ ANTI- THEFT W/O ANTI- THEFT
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlamps/fog lamps circuit, with drl -> LEFT HEADLAMP RETRACTOR
Wiring diagram left headlamp retractor (2 of 2)
15 42 (2.5L) (2.OL)
2.5L
ANTI-THEFT SYSTEM
BLK WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/RED WIRE
CENTRAL PROCESSING UNIT (BEHIND LEFT SIDE OF INST PANEL, NEAR FUSE PANEL)
COMBINATION SWITCH MAIN LIGHT SWITCH
DOWN
ENGINE COMPARTMENT FUSE BOX
FOG LAMP RELAY (IN ENGINE COMPT FUSE BOX)
FOG LAMP SWITCH
HEAD
HEAD FUSE
HEADLAMP RELAY (LEFT SIDE OF ENGINE COMPT, IN ENGINE COMPT FUSE BOX)
HEADLAMP RETRACTOR CONTROL
HEADLAMP RETRACTOR TEST CONNECTOR
HEADLTS ON INPUT
HI BEAM INDICATOR
HI BEAMS INPUT
HI LO HI LEFT HEADLIGHT
HOT AT ALL TIMES
INSTRUMENT CLUSTER
JOINT CONNECTOR
LEFT FOG LIGHT
LEFT HEADLAMP RETRACTOR
LO RIGHT HEADLIGHT
NCA WIRE
OFF
ON INDIC- ATOR
ORG/ WIRE
ORG/BLK WIRE
PARK OFF
POWER
POWERTRAIN CONTROL MODULE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RETRA FUSE
RIGHT FOG LIGHT
RIGHT HEADLAMP RETRACTOR
TO DIMMER PASS LO HI
W/ ANTI- THEFT W/O ANTI- THEFT
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Headlamps/fog lamps circuit, without drl -> LEFT HEADLAMP RETRACTOR
