Ford Probe II (1992-1997) left door lock sw Wiring diagram
This page shows the only wiring diagram for the component.left door lock sw, which is found in the car Ford Probe II (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left door lock sw (1 of 1)
AIR BAG DIAGNOSTIC MODULE
BLK WIRE
BLK/GRN WIRE
BLK/PNK WIRE
BLU WIRE
CENTRAL PROCESSING UNIT
DOME/ MAP LT ASSEMBLY
FUEL PUMP MODULE
HI MOUNT STOP LT
INTERIOR FUSE PANEL
JOINT CONNECTOR
KEYLESS ENTRY MODULE
LEFT DOOR HANDLE SW
LEFT DOOR KEY CYLINDER SW
LEFT DOOR LOCK SW
LEFT LICENSE LT
LEFT REAR COMBINATION LT
LEFT VANITY MIRROR LT
LIFTGATE KEY SW
LUGGAGE COMPARTMENT LAMP SW
MASTER WINDOW DOOR LOCK CONTROL SW
NCA WIRE
PNK WIRE
POWER ANTENNA
POWER DOOR LOCK RELAY
POWER LUMBAR/ BOLSTER COMPRESSOR MOTOR SEAT BELT BUCKLE SW
POWER MIRROR SWITCH
POWER SEAT SW
RADIO, AMPLIFIER
RADIO/CD PLAYER
REAR WINDOW DEFROST GRID
RIGHT DOOR HANDLE SW
RIGHT DOOR KEY CYLINDER SW
RIGHT DOOR LOCK SW
RIGHT LICENSE LT
RIGHT REAR COMBINATION LT
RIGHT VANITY MIRROR LT
SUBWOOFER AMPLIFIER
WHT WIRE
Go to component -> Ground distribution circuit (4 of 4) -> LEFT DOOR LOCK SW
