Ford Probe II (1992-1997) hot in run or start interior fuse panel Wiring diagram
This page shows the only wiring diagram for the component.hot in run or start interior fuse panel, which is found in the car Ford Probe II (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in run or start interior fuse panel (1 of 1)
2.0L 2.5L
2.5L ONLY
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER RADIATOR CRASH SENSOR (ENGINE COMPARTMENT NEAR HOOD LATCH)
CLOCK SPRING ASSEMBLY
DATA LINK CONNECTOR (LEFT FRONT FENDER APRON)
DRIVER'S AIR BAG
ENGINE COMPARTMENT FUSE BLOCK
ENGINE FUSE
F/P-INJ FUSE
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GY/ORG WIRE
HOT AT ALL TIMES
HOT IN RUN OR START INTERIOR FUSE PANEL
INSTRUMENT CLUSTER AIR BAG INDICATOR
JOINT CONNECTOR (BEHIND LEFT SIDE I/P)
JOINT CONNECTOR (BEHIND TOP LEFT
LEFT CRASH SENSOR
NCA WIRE
PASSENGER'S AIR BAG
RED WIRE
RED/GRN WIRE
RIGHT CRASH SENSOR
SAFING SENSOR (BEHIND CENTER OF I/P)
SHORT BAR
SHORTING BAR
SHORTING BARS
SIDE OF I/P)
WHT WIRE
WHT/GRN WIRE
Go to component -> Supplemental restraint circuit -> HOT IN RUN OR START INTERIOR FUSE PANEL
