Ford Probe II (1992-1997) glove box lt sw Wiring diagram
This page shows the only wiring diagram for the component.glove box lt sw, which is found in the car Ford Probe II (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram glove box lt sw (1 of 1)
2.0L
2.0L, 2.5L W/ ABS AND CRUISE CONTROL
2.5L
2.5L M/T
2.5L ONLY
A/C HIGH PRESSURE CUTOUT/ FAN SW
A/C RELAY
ABS MAIN RELAY
AIR BAG DIAGNOSTIC MODULE
BLK WIRE
BLK/BLU WIRE
BRAKE FLUID LEVEL SW
CANADA
CIGAR LIGHTER
CLOCK SPRING ASSY CLUTCH PEDAL POS SW
COMBINATION SW
DATA LINK CONN
DAYTIME RUNNING LAMPS CONTROL MODULE
ELECTRIC COOLING FAN MOTOR CONDENSER FAN MOTOR
ENGINE COMPARTMENT FUSE BOX
FOG LT RELAY
FOG LT SW
FOG LTS
FROM COMBINATION SW 2.0L W/O ABS
GLOVE BOX LT SW
GRY WIRE
HEATER- A/C HEATER CONTROL ASSY 2.5L
HOOD SW
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMING MODULE
JOINT CONNECTOR
LEFT FRONT COMBINATION LT
LEFT HEADLT
LEFT HEADLT RETRACTOR
LEFT RIGHT
LIFTGATE WIPER SW FLASHER MODULE
NCA WIRE
PCM POWER RELAY
RADIO NOISE CAPACITOR
REAR WINDOW DEFROST SW LIFTGATE WASHER SW
RIGHT FRONT COMBINATION LT
SPEED CONTROL MODULE
TACHOMETER SIGNAL SHIELD PARK RANGE SW
TRANSMISSION CONTROL SW
WASHER FLUID LEVEL SW RIGHT HEADLT RETRACTOR
WINDSHIELD WASHER MOTOR
Go to component -> Ground distribution circuit (2 of 4) -> GLOVE BOX LT SW
