Ford Probe II (1992-1997) fwd/rwd slide switch Wiring diagram
This page shows the only wiring diagram for the component.fwd/rwd slide switch, which is found in the car Ford Probe II (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fwd/rwd slide switch (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
FUSE BLOCK
FWD/RWD SLIDE SWITCH
GRN WIRE
HOT AT ALL TIMES
JOINT CONNECTOR (BELOW LEFT FRONT SEAT)
LIFT SWITCH
LUMBAR SUPPORT SWITCH
NCA WIRE
NOT USED
POWER LUMBAR/BOLSTER SWITCH
POWER LUMBER/BOLSTER COMPRESSOR MOTOR
POWER SEAT FUSE
POWER SEAT LIFT MOTOR
POWER SEAT SLIDE MOTOR
POWER SEAT SWITCH
POWER SEAT TILT MOTOR
RED WIRE
RWD
SIDE SUPPORT SWITCH
TILT SWITCH
UNDERHOOD
UP DN
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power seat circuits -> FWD/RWD SLIDE SWITCH
