Ford Probe II (1992-1997) defog fuse fuse block Wiring diagram
This page shows the only wiring diagram for the component.defog fuse fuse block, which is found in the car Ford Probe II (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram defog fuse fuse block (1 of 1)
23 15 16 (2.0L M/T CALIF. OR A/T) (2.0L M/T) (2.5L)
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLK/YEL WIRE
DEFOG FUSE FUSE BLOCK
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
INTERIOR FUSE PANEL
JOINT CONNECTOR
JUNCTION CONNECTORS (BEHIND LEFT SIDE OF I/P TAPED TO I/P HARNESS)
METER FUSE
NOT USED NOT USED
OFF ON
ORG/ WIRE
POWERTRAIN CONTROL MODULE (BELOW FRONT OF CENTER CONSOLE)
PPL
REAR WINDOW DEFROST GRID
REAR WINDOW DEFROST RELAY (RIGHT FRONT RADIATOR SUPPORT)
REAR WINDOW DEFROST SWITCH
SWITCH ILLUMINATION
TIMER
