Ford Probe II (1992-1997) backup lamp switch input Wiring diagram
This page shows the only wiring diagram for the component.backup lamp switch input, which is found in the car Ford Probe II (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backup lamp switch input (1 of 1)
BACKUP LAMP SWITCH INPUT
BAT IGN
BLK WIRE
BLK/YEL WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
CENTRAL PROCESSING UNIT
CENTRAL PROCESSING UNIT PARK AND HEAD LAMPS ON CIRCUIT
DOOR INPUT
EXTERIOR LIGHTS SYSTEM (BACKUP LAMPS)
EXTERIOR LIGHTS SYSTEM (PARK LAMP RELAY)
FASTEN BELTS INDICATOR
FASTEN SEAT BELT INDICATOR OUTPUT
GROUND
HOT AT ALL TIMES
HOT AT ALL TIMES ROOM FUSE
HOT IN RUN OR START
IGNITION KEY REMINDER SWITCH
IGNITION KEY REMINDER SWITCH INPUT
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
INTERIOR FUSE PANEL
INTERIOR FUSE PANEL (LEFT SIDE OF I/P)
JOINT CONNECTOR (BELOW LEFT FRONT SEAT)
LEFT DOOR COURTESY LAMP SWITCH
METER FUSE
METER ROOM
NCA WIRE
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT DOOR COURTESY LAMP SWITCH
ROOM FUSE
SEAT BELT BUCKLE SWITCH
SEAT BELT BUCKLED INPUT
START/RUN POWER
WHT WIRE
Go to component -> Warning system circuits -> BACKUP LAMP SWITCH INPUT
