Wiring diagram engine performance 4.9ls for Ford Pickup F350 (1996-1997)

AIR CONDITIONING SYSTEM BLK WIRE BLK/LT BLU WIRE BLK/LT GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/PNK WIRE COIL DATA LINK CONNECTOR DISTRIBUTOR (LEFT FRONT OF ENGINE) DISTRIBUTOR IGNITION SHIELD DK GRN/ORG WIRE DK GRN/YEL WIRE ENGINE COMPARTMENT FUSE BOX (LEFT SIDE OF ENGINE COMPARTMENT) FUSE 22 FUSE 9 GRY WIRE GRY/ORG WIRE HOT AT ALL TIMES HOT IN START OR RUN IDM (FTO) IGNITION COIL (LEFT FRONT OF ENGINE, FORWARD OF DISTRIBUTOR) IGNITION CONTROL MODULE (LEFT REAR SIDE OF ENGINE COMPARTMENT, ON FENDER APRON) INDICATOR SWITCH LT BLU/BLK WIRE LT GRN/RED WIRE NCA WIRE ORG/BLK WIRE ORG/RED WIRE ORG/YEL WIRE PCM POWER DIODE PCM POWER RELAY PIP PNK WIRE PNK/LT BLU WIRE PNK/LT GRN WIRE PNK/ORG WIRE POWER POWERTRAIN CONTROL MODULE (TOP LEFT SIDE OF SAFETY WALL) PPL PPL/ORG WIRE PWR GRD RADIO CAPACITOR (LEFT FRONT OF ENGINE, NEAR COIL) RED WIRE RED/ LT GRN WIRE RED/LT GRN WIRE SPARK OUTPUT CHECK CONNECTOR (LEFT REAR OF ENGINE COMPARTMENT, NEAR ICM) SPOUT TAN/LT BLU WIRE TAN/ORG WIRE TAN/WHT WIRE TAN/YEL WIRE TRANS- MISSIONS SYSTEM 784 915 WHT/PNK WIRE YEL WIRE YEL/BLK WIRE

BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/LT GRN WIRE BRN/PNK WIRE BRN/WHT WIRE DELTA PRESSURE FEEDBACK EGR SENSOR (LEFT SIDE OF ENGINE) DK GRN/LT GRN WIRE DK GRN/YEL WIRE ENGINE COMPARTMENT FUSE BOX (LEFT SIDE OF ENGINE COMPARTMENT) FUEL PUMP RELAY FUSE 16 GRY WIRE GRY/BLK WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER INTAKE AIR TEMPERATURE SENSOR (RIGHT FRONT OF ENGINE, NEAR INTAKE RUNNER #1) KNOCK SENSOR (LEFT FRONT OF ENGINE, NEAR IGNITION COIL) LT BLU/ORG WIRE LT GRN/RED WIRE MALFUNCTION INDICATOR INPUT MISFIRE SENSOR (CENTER FRONT OF ENGINE, ON TIMING CHAIN COVER) NCA WIRE ORG/BLK WIRE ORG/YEL WIRE PNK/LT GRN WIRE PPL/ORG WIRE PSOM VEHICLE SPEED OUTPUT RED WIRE RED/LT GRN WIRE RPM INPUT TAN/LT BLU WIRE TAN/WHT WIRE THROTTLE POSITION SENSOR (TOP LEFT REAR OF ENGINE, ON THROTTLE BODY) WHT/PNK WIRE YEL WIRE YEL/RED WIRE

BLK WIRE BLK/WHT WIRE BRN WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/ORG WIRE BRN/PNK WIRE BRN/WHT WIRE BRN/YEL WIRE COAST CLUTCH SOLENOID DK GRN WIRE DK GRN/LT GRN WIRE DK GRN/YEL WIRE EGR VACUUM REGULATOR SOLENOID (LEFT REAR OF ENGINE, BELOW EGR VALVE) ELECTRONIC PRESSURE CONTROL SOLENOID EVAPORATIVE CANISTER PURGE VALVE (REAR CENTER OF ENGINE COMPARTMENT) FUEL INJECTORS FUEL PUMP/ FUEL GAUGE SENDER (TOP RIGHT OF TANK) GRY/BLK WIRE GRY/RED WIRE GRY/WHT WIRE IDLE AIR CONTROL VALVE (TOP LEFT SIDE OF ENGINE) INERTIA FUEL SHUTOFF SWITCH (RIGHT KICK PANEL) LT BLU/ORG WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE NCA WIRE ORG/BLK WIRE ORG/YEL WIRE PNK/BLK WIRE PPL/ORG WIRE PPL/YEL WIRE RED WIRE RED/LT GRN WIRE SECONDARY AIR INJECTION BYPASS SOLENOID (TOP LEFT REAR OF ENGINE) SECONDARY AIR INJECTION DIVERTER SOLENOID (TOP LEFT REAR OF ENGINE) SHIFT SOLENOIDS TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/WHT WIRE TORQUE CONVERTER CLUTCH SOLENOID TRANSMISSION FLUID TEMPERATURE SENSOR WHT WIRE WHT/LT BLU WIRE WHT/ORG WIRE WHT/YEL WIRE YEL WIRE YEL/RED WIRE

BLK/WHT WIRE BRAKE ON/OFF (BOO) SWITCH (UNDER LEFT SIDE OF I/P) BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE DK GRN/LT GRN WIRE FUSE 13 FUSE PANEL (LEFT SIDE OF I/P) FUSE 17 GRY/BLK WIRE GRY/LT BLU WIRE GRY/RED WIRE GRY/WHT WIRE HEATED OXYGEN SENSOR 11 (LOWER RIGHT REAR OF ENGINE) HEATED OXYGEN SENSOR 12 (NEAR CATALYTIC CONVERTER) HEATED OXYGEN SENSOR 21 (LOWER LEFT REAR OF ENGINE) HOT AT ALL TIMES HOT IN RUN OR START LT BLU/ORG WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE MAF SENS IN TP SENS IN REF VOLT SIG RTN BRAKE ON/OFF MASS AIR FLOW SENSOR (RIGHT FRONT SIDE OF ENGINE COMPARTMENT) NCA WIRE POWERTRAIN CONTROL MODULE (TOP LEFT SIDE OF SAFETY WALL) PPL/YEL WIRE RED WIRE RED/BLK WIRE RED/LT GRN WIRE RED/WHT WIRE RED/YEL WIRE TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/WHT WIRE TRANS- MISSION CONTROL SWITCH (TOP OF STEERING COLUMN) TRANSMISSION RANGE SENSOR (LOWER LEFT SIDE OF TRANSMISSION) WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/ORG WIRE WHT/YEL WIRE YEL WIRE YEL/LT BLU WIRE YEL/RED WIRE
