Driver"s memory seat circuit, early production for Ford Pickup F350 Super Duty (1999-2012)

1 2 PWR GND V BATT ADJUSTABLE PEDAL CIRCUIT BLK WIRE BLK/VIO WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER SEAT MODULE (UNDER DRIVER SEAT) DRIVER SIDE SEAT CONTROL SWITCH EFF SNS RET FRONT UP/ DOWN FRONT UP/DOWN FRT TILT DN SW HORZ BASE FORE RR TILT DN SW FRT TILT UP SW HORZ BASE AFT RR TILT UP SW FUSE BOX (ON PASSENGER SIDE KICK PANEL) FWD BACK GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/RED WIRE GRY/VIO WIRE GRY/YEL WIRE HALL EFF SN RR TILT MTR UP FRT TILT MTR UP HORZ BASE AFT HORZ BASE FORE HORZ FWD/ RWD HOT AT ALL TIMES HOT AT ALL TIMES BATTERY JUNCTION FUSE BOX (BJB) (AT LEFT REAR OF ENGINE COMPT) LEFT POWER SEAT MOTOR ASSEMBLY (IN DRIVER SEAT BOTTOM) MEMORY MIRRORS CIRCUIT MEMORY SET SWITCH REAR TILT EFF HORZ BASE EFF SEAT HALL EFF REAR TILT MTR FRT TILT MTR DN REAR UP/ DOWN REAR UP/DOWN RED WIRE SMART JUNCTION VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/ORG WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE
