All-wheel abs circuit for Ford Pickup F350 Super Duty (1999-2012)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 ABS IND CTRL 1 2 GROUND POWER (B+) 4-WHEEL ANTI-LOCK BRAKE ANTI-LOCK BRAKE INDICATOR BATTERY JUNCTION BOX (IN LEFT SIDE OF ENGINE COMPT, ON TOP OF WHEELWELL) FUSE 14 BLK WIRE BRAKE FLUID LEVEL SW BRAKE FLUID LEVEL SWITCH (ON BRAKE FLUID RESERVOIR) BRAKE PEDAL POSITION (BPP) SWITCH (BEHIND LEFT SIDE OF DASH, ABOVE BRAKE PEDAL) CENTRAL JUNCTION BOX (BEHIND LOWER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR (BEHIND CENTER OF DASH) DIAGNOSTIC CIRCUIT DIFFERENTIAL SPEED SENSOR (DSS) (ON CENTER OF REAR AXLE) DK GRN WIRE DK GRN/YEL WIRE FUSE 15 FUSE 19 FUSE 24 GENERIC ELECTRONIC MODULE (GEM) (BEHIND LOWER LEFT SIDE OF DASH) GRY/BLK WIRE HOT AT ALL TIMES HOT IN RUN HOT IN RUN OR START IGNITION FEED BPP SWITCH FEED VSS (+) INSTRUMENT CLUSTER LEFT FRONT ANTI-LOCK BRAKE SENSOR (AT WHEEL) LT BLU WIRE LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN/BLK WIRE LT GRN/YEL WIRE NCA WIRE OHM ORG/YEL WIRE PNK/ORG WIRE REAR SENSOR (HIGH) RIGHT FRONT SENSOR (HIGH) LEFT FRONT SENSOR (HIGH) REAR SENSOR (LOW) RIGHT FRONT SENSOR (LOW) LEFT FRONT SENSOR (LOW) RED/LT GRN WIRE RED/PNK WIRE RED/YEL WIRE RIGHT FRONT ANTI-LOCK BRAKE SENSOR (AT WHEEL) TAN/BLK WIRE TAN/LT GRN WIRE TAN/ORG WIRE TAN/RED WIRE TRANSMISSIONS SYSTEM WHT/VIO WIRE YEL/BLK WIRE YEL/RED WIRE
