Back-up lamps circuit for Ford Pickup F250 (1996-1999)
Back-up lamps circuit
A/T
ANTI-THEFT SYSTEM (RAP MODULE)
BLK WIRE
BLK/PNK WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DIGITAL TRANSMISSION RANGE (DTR) SENSOR (ON LEFT SIDE OF TRANSMISSION)
EXTERIOR LAMPS (TRAILER TOW CIRCUIT)
FUSE 5
HOT IN RUN
LT BLU WIRE
M/T
PNK LEFT REVERSING LAMP WIRE
PNK RIGHT REVERSING LAMP WIRE
PNK WIRE
REVERSING LAMP SWITCH (ON LEFT SIDE OF TRANSMISSION)
