Wiring Diagrams for Ford Pickup F250 (1996-1999)

A/c circuit Heater circuit Manual a/c circuit

4.9l, a/c circuit Heater circuit

5.0l, a/c circuit Heater circuit

5.8l, a/c circuit Heater circuit

7.3l di turbo diesel, air conditioning circuits Heater circuit

7.5l, a/c circuit Heater circuit

All-wheel abs circuit Anti-lock brake circuits Rear wheel abs circuit

Anti-theft circuit Forced entry circuit Passive anti-theft circuit

Body computer circuits

Computer data lines

4.9l, computer data lines

5.0l, computer data lines

5.8l, computer data lines, over 8500 gvwr 5.8l, computer data lines, under 8500 gvwr

7.3l di turbo diesel, computer data lines

7.5l, computer data lines, california 7.5l, computer data lines, federal

Cruise control circuit

4.9l, cruise control circuit

5.0l, cruise control circuit

5.8l, cruise control circuit

7.3l di turbo diesel, cruise control circuit

7.5l, cruise control circuit

Electronic suspension circuit

Wiring diagram engine performance 4.6ls

Wiring diagram engine performance 4.9ls

Wiring diagram engine performance 5.0ls, with 4r70w transmission (1 of 4) Wiring diagram engine performance 5.0ls, with 4r70w transmission (2 of 4) Wiring diagram engine performance 5.0ls, with 4r70w transmission (3 of 4) Wiring diagram engine performance 5.0ls, with 4r70w transmission (4 of 4) Wiring diagram engine performance 5.0ls, with e4od transmission (1 of 4) Wiring diagram engine performance 5.0ls, with e4od transmission (2 of 4) Wiring diagram engine performance 5.0ls, with e4od transmission (3 of 4) Wiring diagram engine performance 5.0ls, with e4od transmission (4 of 4)

Wiring diagram engine performance 5.4l cngs Wiring diagram engine performance 5.4ls

Wiring diagram engine performance 5.8ls, over 8500 gvwr Wiring diagram engine performance 5.8ls, under 8500 gvwr

Wiring diagram engine performance 7.3l di turbo diesels

Wiring diagram engine performance 7.5ls, california Wiring diagram engine performance 7.5ls, federal

Back-up lamps circuit Backup lamps circuit Exterior lamps circuit Trailer/camper adapter circuit Trailer tow circuit

Ground distribution circuit

Autolamps & fog lamps circuit, with drl Autolamps/fog lamps circuit, with drl Autolamps & fog lamps circuit, without drl Autolamps/fog lamps circuit, without drl Headlamps & fog lamps circuit, with drl Headlamps/fog lamps circuit, with drl Headlamps & fog lamps circuit, without drl Headlamps/fog lamps circuit, without drl Headlight circuit, with drl Headlight circuit, without drl

Horn circuit

Instrument cluster circuit

Courtesy lamps circuit Courtesy lamps circuit, with keyless entry Courtesy lamps circuit, without keyless entry Instrument illumination circuit

Power distribution circuit

Door lock circuit Keyless entry circuit

Power mirror circuit

Lumbar/bolster circuit, with captain's chairs Lumbar circuit, with captain's chairs Lumbar circuit, with cloth bench Power seat circuit Power seat circuits

Power window circuit Power window circuit, with crew cab Power window circuit, without crew cab

Base radio Premium sound radio circuit Radio circuits, with cd changer Radio circuits, without cd changer

Shift interlock circuit

Charging circuit Starting circuit Starting circuit, a/t Starting circuit, m/t

4.9l, charging circuit 4.9l, starting circuit

5.0l, charging circuit 5.0l, starting circuit

5.8l, charging circuit 5.8l, starting circuit

7.3l di turbo diesel, charging circuit, with 130 a alternator 7.3l di turbo diesel, charging circuit, with 200 a alternator 7.3l di turbo diesel, starting circuit

7.5l, charging circuit 7.5l, starting circuit

Supplemental restraint circuit

4.6l, a/t circuit, 4r70w 4.6l, transmission circuit, 4r70w 4wd circuit, electronic 4wd circuit, mechanical Transfer case circuit, electronic Transfer case circuit, mechanical

4.9l, transmission circuit

5.0l, 4r7ow transmission circuit 5.0l, e4od transmission circuit

4wd circuit, electronic 4wd circuit, mechanical 5.4l, a/t circuit, 4r100 5.4l, a/t circuit, 4r70w 5.4l cng, a/t circuit, 4r100 5.4l cng, transmission circuit, e4od 5.4l, transmission circuit, e4od Transfer case circuit, electronic Transfer case circuit, mechanical

5.8l, transmission circuit, over 8500 gvwr 5.8l, transmission circuit, under 8500 gvwr

7.3l di turbo diesel, transmission circuit

7.5l, transmission circuit, california 7.5l, transmission circuit, federal

Warning system circuits

Wiper/washer circuit

4 WHEEL ANTI- LOCK BRAKE SYSTEM MODULE 4 WHEEL ANTI-LOCK BRAKES 4-WHEEL ANTI-LOCK BRAKE SYSTEM A/C CLUTCH DIODE A/C CLUTCH DIODE RIGHT FRONT SIDE MARKER LAMPS A/C CLUTCH FIELD COIL A/C CLUTCH RESISTOR DIODE ALL LOCK/ ALTERNATOR) BATTERY ANTI- BIAS CIRCUIT LOCK IND ANTI- LOCK IND BIAS CKT ANTI-LOCK BRAKE IND ANTI-LOCK BRAKE MODULE ANTI-LOCK BRAKES ANTI-LOCK IND AUTOLAMP MODULE, INSTR CLUSTER, BRAKE WARNING RESISTOR ASSY BATTERY CHARGE BATTERY JUNCTION BOX BATTERY JUNCTION BOX 5.4L BATTERY POWER BATTERY SAVER INPUT CASE GND IGN COIL 1 IGN COIL 5 COIL ON COIL ON COIL ON RADIO PLUG 1 PLUG 2 PLUG 3 NOISE CAPACITOR 1 COIL ON COIL ON PLUG 4 PLUG 5 COIL ON COIL ON PLUG 6 PLUG 7 COIL ON PLUG 8 CRUISE CONTROL SERVO/AMPLIFIER ASSEMBLY DAYTIME RUNNING LAMPS RESISTOR DIESEL WITH 200 A GENERATOR HORN SWITCHES IGNITION COIL IGNITION RADIO COIL NOISE CAPACITOR LEFT BATTERY LOCK OFF LOCK UNLOCK MAIN HARNESS, NEAR BREAK OUT TO SPEED CONTROL AMPLIFIER OFF LOCK PASSIVE ANTI-THEFT SYSTEM TRANSCEIVER MODULE PCM POWER DIODE PWR GND CASE GND IGN COIL 1 SHIFT SOL A PWR GND IGN COIL 2 PWR GND IGN COIL 3 PWR GND IGN COIL 4 PWR GND IGN COIL 7 IGN COIL 8 FUEL CTRL EPC SOL PWR GND IGN COIL 7 IGN COIL 8 FUEL PUMP CTRL EPC SOL REAR ANTI-LOCK BRAKE MODULE REAR ANTI-LOCK BRAKE SYSTEM MODULE REAR WHEEL ANTI-LOCK BRAKES SYSTEM MODULE RIGHT BATTERY SPEED CONTROL SERVO/ AMPLIFIER ASSEMBLY SPEED CONTROL SERVO/AMPLIFIER ASSEMBLY SPEED CONTROL/ HORN

(ENGINE COMPT HARN, NEAR BREAKOUT (LEFT SIDE ENGINE COMPARTMENT BLEND DOOR ACTUATOR BLOWER MOTOR BLOWER MOTOR RESISTOR BLOWER MOTOR RESISTORS CHECK ENGINE IND ENGINE COMPART- MENT LAMP ENGINE COMPARTMENT LAMP ENGINE CONTROLS ENGINE CONTROLS SYSTEM ENGINE WARNING IND. FORWARD/REVERSE MOTOR FRONT HEIGHT MOTOR GLOVE COMPARTMENT LAMP BLOWER MOTOR RESISTOR LEFT DOOR LOCK MOTOR LEFT FRONT WINDOW MOTOR LEFT POWER LUMBAR COMPRESSOR MOTOR LEFT POWER LUMBAR COMPRESSOR MOTOR POWER LUMBAR COMPRESSOR MOTOR LEFT POWER LUMBAR/ BOLSTER COMPRESSOR MOTOR LEFT POWER LUMBAR/BOLSTER COMPRESSOR MOTOR LEFT POWER WINDOW MOTOR LEFT REAR WINDOW MOTOR LOWER RIGHT FRONT OF ENGINE) OF ENGINE COMPARTMENT ON UPPER RADIATOR SUPPORT) POWER LUMBAR COMPRESSOR MOTOR POWER SEAT MOTOR ASSEMBLY REAR AIR SUSPENSION COMPRESSOR MOTOR AND VENT SOLENOID REAR AIR SUSPENSION COMPRESSOR MOTOR/ VENT SOLENOID REAR HEIGHT MOTOR REAR OF ENGINE COMPT) RIGHT DOOR LOCK MOTOR RIGHT FRONT WINDOW MOTOR RIGHT POWER LUMBAR COMPRESSOR MOTOR RIGHT POWER LUMBAR/ BOLSTER COMPRESSOR MOTOR RIGHT POWER WINDOW MOTOR RIGHT REAR WINDOW MOTOR SHIFT LOCK ACTUATOR SHIFT LOCK ACTUATOR INSTRUMENT CLUSTER SHIFT LOCK ACTUATOR, REAR AIR SUSPENSION MODULE SHIFT MOTOR SOUND SYSTEM ENGINE CONTROLS SYSTEM ELECTRONIC SUSPENSION SYSTEM SPEED CONTROL SERVO ENGINE COMPARTMENT LAMP STARTER MOTOR STARTER MOTOR/ SOLENOID HOLD W/ GASOLINE ENGINE W/ DIESEL ENGINE WIND- SHIELD WASHER PUMP MOTOR LEFT FRONT PARK/ TURN LAMP WIND- SHIELD WIPER MOTOR WINDSHIELD WASHER PUMP MOTOR WINDSHIELD WIPER MOTOR WINDSHIELD WIPER MOTOR A/C CLUTCH DIODE

200 A GENERATOR/ VOLTAGE REGULATOR GENERATOR, VOLTAGE REGULATOR

AUXILIARY POWER SOCKET CENTRAL TIMER MODULE DIAGNOSTIC CONNECTOR DATA LINK CONNECTOR ENABLE PSOM PROGRAMMING CONNECTOR PNK RABS DATA LINK CONNECTOR WIRE POWER MIRROR SWITCH DATA LINK CONNECTOR RABS DATA LINK CONNECTOR TRAILER ELECTRICAL CONNECTOR TRAILER TOW CONNECTOR TRAILER TOW CONNECTOR TRAILER ELECTRONIC BRAKE CONTROL

AIR BAG CONTROL MODULE CONTROL MODULE ELECTRONIC SHIFT CONTROL MODULE IGNITION CONTROL MODULE MAIN LIGHT SWITCH WINDSHIELD WIPER MOTOR WIPER CONTROL MODULE POWER- TRAIN CONTROL MODULE POWER- TRAIN CONTROL MODULE PPL POWERTRAIN CONTROL MODULE REAR ABS CONTROL MODULE RESTRAINT CONTROL MODULE WIPER CONTROL MODULE

TO ELECTRIC TRAILER BRAKE CONTROL UNIT TO TRAILER ELECTRONIC BRAKE CONTROL UNIT

BATTERY JUNCTION BOX FUSE 7 CENTRAL JUNCTION BOX FUSE 30 ENGINE COMPARMENT FUSE BOX ENGINE COMPART- MENT FUSE BOX ENGINE COMPART- MENT FUSE BOX FUSE 22 ENGINE COMPARTMENT FUSE BOX ENGINE COMPARTMENT FUSE BOX FUSE 22 ENGINE FUSE MODULE FUSE 2 FROM FUSE 8 FUSE 1 FUSE 2 FUSE 2 FUSE 1 FUSE 3 FUSE 4 FUSE 5 FUSE 6 FUSE 6 FUSE 2 FUSE 7 FUSE 7 FUSE 6 FUSE 7 FUSE 18 FUSE 8 FUSE 9 FUSE 10 FUSE 10 FUSE 18 FUSE 11 FUSE 11 CIRCUIT BREAKER 14 FUSE 13 FUSE 14 FUSE 14 FUSE 4 FUSE 15 FUSE 15 FUSE 20 FUSE 16 FUSE 16 FUSE 5 FUSE 16 FUSE 28 FUSE 17 FUSE 18 FUSE 19 FUSE 20 FUSE 21 FUSE 21 FUSE 5 FUSE 22 FUSE 23 FUSE 24 FUSE 25 FUSE 26 FUSE 27 FUSE 27 FUSE 26 FUSE 28 FUSE 28 FUSE 26 FUSE 28 FUSE 26 FUSE 27 FUSE 29 FUSE 29 FUSE 30 FUSE 30 FUSE 101 FUSE 101 FUSE 7 FUSE 102 FUSE 103 FUSE 103 FUSE 108 FUSE 112 FUSE 104 FUSE 105 FUSE 108 FUSE 109 FUSE 110 FUSE 111 FUSE 112 FUSE 113 FUSE BLOCK FUSE FUSE 6 FUSE LINK A (12 GA- FUSE LINK B (12 GA- FUSE LINK C (14 GA- FUSE LINK D FUSE LINK D (14 GA- FUSE LINK J (12 GA- FUSE LINK K (12 GA- DIESEL ONLY FUSE PANEL FUSE PANEL FUSE 3 FUSE PANEL FUSE 13 FUSE PANEL FUSE 17 GENERIC ELECTRONIC MODULE FUSE 30 HOT AT ALL TIMES BATTERY JUNCTION BOX FUSE 6 HOT AT ALL TIMES BATTERY JUNCTION BOX FUSE 9 HOT AT ALL TIMES BATTERY JUNCTION BOX FUSE 105 HOT AT ALL TIMES FUSE 7 HOT AT ALL TIMES POWER DISTRIBUTION BOX FUSE 9 HOT AT ALL TIMES POWER DISTRIBUTION BOX FUSE 23 HOT IN RUN FUSE 5 HOT IN RUN INSTRUMENT PANEL FUSE BOX HOT IN RUN OR START HOT IN RUN FUSE 18 FUSE 17 MEGA FUSE TO FUSE 7

A/C- HEATER CONTROL ASSEMBLY HEATER CONTROL ASSEMBLY A/C-HEATER CONTROL ASSEMBLY FUEL LINE HEATER HEATER CONTROL ASSEMBLY HEATER CONTROL ILLUMINATION HEATER CTRL

608 649 INDICATOR DRIVER GROUND 820 OHMS TRANSMISSION CONTROL INDICATOR LAMP O/D OFF "ANTI-THEFT" INDICATOR "HIGH RANGE" INDICATOR "LOW RANGE" INDICATOR AIR BAG INDICATOR BRAKE FLUID LEVEL INDICATOR SWITCH BRAKE FLUID LEVEL WARNING INDICATOR BRAKE WARNING INDICATOR CHARGE INDICATOR FUEL RESET SWITCH INDICATOR HI BEAM INDICATOR INDICATOR SWITCH INSTRUMENT CLUSTER CHECK SUSPENSION INDICATOR INSTRUMENT CLUSTER HI BEAM INDICATOR LEFT TURN INDICATOR MALFUNCTION INDICATOR MALFUNCTION INDICATOR INPUT MALFUNCTION INDICATOR LAMP RIGHT TURN INDICATOR THEFT INDICATOR MICRO CLUSTER TRANSMISSION CONTROL INDICATOR LAMP

AUTO- LAMP ON AUTO- LAMP ON IND BACKUP LAMP CIRCUIT CAP CENTER HIGH MOUNT STOP LAMP CENTER HIGH MOUNT STOP LAMP COURTESY LAMP INPUT EXT LIGHTS EXT LIGHTS START INTRPT INT LIGHTS ALL UNLOCK POWER EXTERIOR LIGHTS FOG LAMP SW FOG LAMP SW FOG ON IND GLOVE COMPART- MENT LAMP GLOVE COMPARTMENT LAMP GLOVE COMPARTMENT LAMP ASHTRAY ILLUMINATION HIGH MOUNT STOP LAMP INT LIGHTS ALL UNLOCK POWER INTERIOR LAMP INTERIOR LIGHTS INTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM POWER WINDOWS SYSTEM INTERIOR/ MAP LAMP LEFT CARGO LAMP LEFT DOOR COURTESY LAMP LEFT DOOR COURTESY LAMP RIGHT DOOR COURTESY LAMP LEFT FOG LAMP LEFT FRONT DOOR COURTESY LAMP LEFT FRONT PARK/ TURN LAMP LEFT FRONT PARK/TURN LAMP LEFT LICENSE LAMP LEFT REAR DOOR COURTESY LAMP LEFT REAR PARK/ STOP/ TURN LAMP LEFT REAR PARK/STOP TURN LAMP LEFT REVERSING LAMP LEFT STOP/ PARK/ TURN LAMP LEFT TAIL/ SIDE LAMP LEFT TAIL/ SIDE MARKER LAMP RIGHT TAIL/ SIDE MARKER LAMP LEFT TURN LAMP LEFT VANITY MIRROR LAMP LICENSE LAMP LICENSE LAMP LICENSE LAMP LICENSE LAMPS LEFT BACKUP LAMP MIL LAMP CTRL OUTSIDE CARGO LAMP REAR DOME LAMP RIGHT BACKUP LAMP RIGHT BACKUP LAMP LEFT BACKUP LAMP RIGHT CARGO LAMP RIGHT DOOR COURTESY LAMP RIGHT FOG LAMP RIGHT FRONT DOOR COURTESY LAMP RIGHT FRONT PARK/ TURN LAMP RIGHT FRONT PARK/TURN LAMP RIGHT HEADLAMP LAMP RIGHT LICENSE LAMP RIGHT REAR DOOR COURTESY LAMP RIGHT REAR PARK/ STOP/ TURN LAMP RIGHT REAR PARK/STOP TURN LAMP RIGHT REVERSING LAMP RIGHT STOP/ PARK/ TURN LAMP RIGHT TAIL/ SIDE LAMP RIGHT TURN LAMP RIGHT VANITY MIRROR LAMP RIGHT VANITY MIRROR LAMP LEFT VANITY MIRROR LAMP WARNING LAMP

FRONT TANK FUEL PUMP/ FUEL GAUGE SENDER FRONT TANK FUEL PUMP/FUEL GAUGE SENDER FUEL PUMP ASSEMBLY FUEL PUMP CTRL FUEL PUMP MODULE IAT FUEL PUMP MON A/C ON SIG IAT FUEL PUMP MON ACCS IAT FUEL PUMP MON ACCS TP OUT PCM DATA OUT REAR TANK FUEL PUMP/ FUEL GAUGE SENDER REAR TANK FUEL PUMP/FUEL GAUGE SENDER WASHER PUMP ASSEMBLY WASHER PUMP ASSEMBLY RIGHT HEADLAMP WIPER SPEED WASHER PUMP

ACCESSORY DELAY RELAY ACCESSORY DELAY RELAY CTRL ALL LOCK RELAY ALL LOCK RELAY ALL UNLOCK RELAY ALL UNLOCK RELAY BATTERY JUNCTION BOX FOG LAMP RELAY BATTERY SAVER RELAY BLOWER RELAY BLOWER RELAY FLASHER RELAY BLOWER/ FLASHER RELAY BLOCK BLOWER/FLASHER RELAY BLOCK BRAKE FLASHER PEDAL RELAY POSITION SWITCH BRAKE/RUN RELAY DAYTIME RUNNING LAMPS RELAY 1 DAYTIME RUNNING LAMPS RELAY 2 DAYTIME RUNNING LAMPS RELAY BLOCK DELAY RELAY DRIVER'S UNLOCK RELAY ENGINE COMPARTMENT FUSE BOX FUEL PUMP RELAY FLASHER RELAY FOG LAMP RELAY FUEL PUMP RELAY FUEL SHUTOFF VALVE RELAY GLOW PLUG RELAY HEADLAMP RELAY HORN RELAY HOT AT ALL TIMES JUNCTION BOX FUSE/RELAY PANEL FUSE 4 HOT IN RUN JUNCTION BOX FUSE/ RELAY BOX FUSE 24 HOT IN RUN JUNCTION BOX FUSE/RELAY PANEL IDM RELAY INSTRUMENT CLUSTER FLASHER RELAY INTER- RUPT RELAY INTERIOR LAMP RELAY INTERIOR LAMP RELAY INPUT JUNCTION BOX FUSE/ RELAY PANEL JUNCTION BOX FUSE/ RELAY PANEL FUSE 20 JUNCTION BOX FUSE/ RELAY PANEL FUSE 21 JUNCTION BOX FUSE/RELAY PANEL LFT REAR SPRING CTRL COMP RELAY CTRL LOCK RELAY BLOCK ONE-TOUCH DOWN RELAY PARK LAMP RELAY PARK LAMP RELAY MAIN LIGHT SWITCH PCM POWER RELAY PCM POWER RELAY FUEL PUMP RELAY PCM POWER RELAY FUSE 2 REAR AIR SUSPENSION COMPRESSOR RELAY RELAY 1 RELAY OUTPUT RPO RELAY BLOCK SHIFT-ON- THE-FLY RELAY STARTER INTERRUPT RELAY STARTER MOTOR RELAY STARTER RELAY TO TRAILER MARKER LAMPS RELAY TO FUSE 6 TRAILER BACKUP LAMP RELAY TRAILER BACKUP LAMPS RELAY TRAILER BACKUP LAMPS RELAY TRAILER BATTERY CHARGE RELAY TRAILER BATTERY CHARGE RELAY TRAILER MARKER LAMPS RELAY TRAILER RELAY BOX TRAILER TOW BACKUP LAMP RELAY TRAILER TOW BATTERY CHARGE RELAY TRAILER TOW BATTERY RELAY TRAILER TOW LEFT TURN RELAY TRAILER TOW REVERSING LAMP RELAY TRAILER TOW RIGHT TURN RELAY TRAILER TOW RUNNING LAMP RELAY TRANSFER CASE ELECTRIC CLUTCH RELAY TRANSFER CASE RETURN BRAKE PEDAL POSITION SWITCH TRNSFER CASE CLUTCH RELAY OUT TRANSFER CASE SHIFT RELAY MODULE WASHER PUMP RELAY WIPER HI/LO RELAY WIPER RUN/PARK RELAY WIPER RUN/PARK RELAY WIPER HI/LO RELAY WOT RELAY

8 9 10 11 12 13 14 21 22 23 24 25 26 SENSOR GROUND (ENGINE CONTROL SENSOR HARN, IN BREAKOUT TO (ENGINE CONTROL SENSOR HARNESS, NEAR BREAK (ENGINE SENSOR HARN, NEAR BREAKOUT TO CAMSHAFT POSITION SENSOR CAMSHAFT POSITION SENSOR SHIELD CRANKSHAFT POSITION SENSOR SHIELD DIFF SPEED SENSOR LOW 10 11 DIFF SPEED SENSOR HIGH BRAKE ON/OFF SW INPUT DIFF SPEED SENSOR LOW 523 511 10 11 DIFF SPEED SENSOR HIGH BRAKE ON/OFF SW INPUT DIGITAL TRANSMISSION RANGE SENSOR EFT SENSOR INJ PRESSURE HEATED OXYGEN SENSOR HEATED OXYGEN SENSOR HEATED OXYGEN SENSOR IDLE AIR CTRL OSS SENSOR CMP SENSOR KS SENSOR MASS AIR FLOW SENSOR OVERHEAD CONSOLE DAY/NIGHT MIRROR AUTOLAMP SENSOR PNK SPEED SENSOR WIRE REAR AXLE SENSOR REAR AXLE SENSOR (ON AXLE REAR AXLE SPEED SENSOR SENSOR POWER RHT REAR SPRING CTRL PNK VENT SOLENOID CTRL WIRE SENSOR SIG RETURN TFT SENSOR SHIFT SOL 2 VEHICLE PWR VEHICLE PWR SIGNAL RTN EPC TRANSFER CASE SPEED SENSOR TRANSMISSION FLUID TEMP SENSOR TRANSMISSION FLUID TEMPERATURE SENSOR TSS SENSOR WOT RELAY DIGITAL TRANS- MISSION RANGE SENSOR BATTERY JUNCTION BOX

LEFT DOOR SPEAKER LEFT FRONT SPEAKER LEFT REAR SPEAKER LEFT REAR SPEAKER OR LEFT REAR DOOR SPEAKER LEFT REAR SPEAKER RIGHT DOOR SPEAKER RIGHT DOOR SPEAKER RIGHT FRONT SPEAKER RIGHT REAR SPEAKER RIGHT REAR SPEAKER OR RIGHT REAR DOOR SPEAKER RIGHT REAR SPEAKER RIGHT DOOR SPEAKER

4 WHEEL ANTI-LOCK BRAKE SYSTEM MODULE MULTI- FUNCTION SWITCH IGNITION SWITCH 4 WHEEL DRIVE MODE SWITCH 4 WHEEL DRIVE MODE SWITCH AIRBAG SLIDING CONTACT (BACKUP LAMP SWITCH TO REAR LAMP FEED HARNESS, IN BREAK OUT (BACKUP LAMP SWITCH TO REAR LAMP FEED HARNESS, IN BREAK OUT TO A/C CLUTCH CYCLING PRESSURE SWITCH A/C HIGH PRESSURE CUT-OUT SWITCH AUTOLAMP MOD, TCS SWITCH, BRAKE WARNING RESISTOR ASSY BACKUP LAMP SWITCH BLOWER MOTOR SWITCH BLOWER MOTOR SWITCH HI BRAKE FLUID LEVEL SWITCH BRAKE PEDAL POSITION SWITCH BRAKE PRESSURE SWITCH CONTROL SWITCH DEACTIVATION SWITCH DIESEL WARNING LAMPS DISPLAY ELECTRONIC SHIFT CONTROL SWITCH DIREC- TIONAL CONTROL SWITCH DRIVE MODE SWITCH ELECTRONIC SHIFT CONTROL SWITCH EXTERIOR REAR VIEW MIRROR SWITCH FROM BRAKE ON/OFF SWITCH FROM IGNITION SWITCH FROM MAIN LIGHT SWITCH FROM MULTI-FUNCTION SWITCH FUEL TANK SELECTOR SWITCH FUEL WATER SWITCH LOW VACUUM WARNING SWITCH FUNCTION SELECTOR SWITCH FUNCTION SELECTOR SWITCH ASSEMBLY FUNCTION SELECTOR SWITCH ASSEMBLY BLEND DOOR ACTUATOR SPEED CONTROL SERVO GEM, RABS MODULE, SHIFT LOCK ACTUATOR, RAP MODULE, CLUTCH PEDAL POSITION SWITCH GND IGNITION SWITCH HI BLOWER MOTOR SWITCH LO MED HI MED LO 3.8 OHMS HI WASHER SWITCH OFF INT MAX LO OHMS INT MIN IGNITION BOO SWITCH IGNITION BPP SWITCH IGNITION FEED BPP SWITCH FEED IGNITION SWITCH INERTIA FUEL SHUT-OFF SWITCH INSIDE CARGO LAMP POWER MIRROR SWITCH LEFT FRONT COURTESY LAMP SWITCH INTERIOR LAMP SWITCH LEFT DOOR AJAR SWITCH LEFT DOOR AJAR SWITCH RIGHT DOOR AJAR SWITCH LEFT FRONT SWITCH LEFT POWER DOOR LOCK SWITCH LEFT POWER LUMBAR SWITCH LEFT POWER LUMBAR SWITCH LEFT POWER LUMBAR/ BOLSTER SWITCH LEFT POWER LUMBAR SWITCH RIGHT WINDOW/ DOOR LOCK CONTROL SWITCH LEFT POWER WINDOW SWITCH LEFT REAR COURTESY LAMP SWITCH RIGHT REAR COURTESY LAMP SWITCH LEFT REAR SWITCH LEFT REAR WINDOW CONTROL SWITCH LEFT SWITCH LEFT WINDOW SWITCH LOW VACUUM WARNING SWITCH LUMBAR SWITCH MAIN LIGHT SWITCH MAIN LIGHT SWITCH DIMMER MODULE MAIN LIGHT SWITCH ENGINE COMPART- MENT LAMP MASTER WINDOW/ DOOR LOCK CONTROL SWITCH MODE SELECTOR SWITCH MULTI- FUNCTION SWITCH MULTI- FUNCTION SWITCH DIMMER MULTI- FUNCTION SWITCH WIPER SWITCH OFF FLOOR PANEL, FLR, DEF FLOOR WARM MODE SELECTOR SWITCH DEF PANEL PARK BRAKE SWITCH PASSENGER AIR BAG DEACTIVATION SWITCH PASSENGER'S AIR BAG DEACTIVATION SWITCH POWER MIRROR SWITCH POWER SEAT CONTROL SWITCH RADIO MASTER TAILGATE WINDOW SWITCH REAR ANTI-LOCK BRAKE SYSTEM MODULE PASSENGER AIRBAG DEACTIVATION SWITCH REAR WINDOW DEFROST SWITCH TURN FLASHER REVERSING LAMP SWITCH RIGHT DOOR AJAR SWITCH RIGHT DOOR LOCK CONTROL SWITCH RIGHT FRONT COURTESY LAMP SWITCH RIGHT FRONT SWITCH RIGHT FRONT WINDOW/ DOOR LOCK SWITCH RIGHT POWER DOOR LOCK SWITCH RIGHT POWER LUMBAR SWITCH RIGHT POWER WINDOW SWITCH RIGHT REAR SWITCH RIGHT REAR WINDOW CONTROL SWITCH RIGHT SWITCH RIGHT WINDOW SWITCH RIGHT WINDOW/ DOOR LOCK CONTROL SWITCH SAFETY BELT WARNING SWITCH SEAT BELT SWITCH SIG RTN BPP SWITCH SPEED CONTROL SWITCH ASSEMBLY SWITCH ASSEMBLY TRANS- MISSION CONTROL SWITCH TRANS- MISSION CONTROL SWITCH INSTRUMENT CLUSTER TRANSMISSION CONTROL SWITCH VALVE RESET SWITCH WINDOW LOCK SWITCH

#1 SHIFT SOLENOID #2 SHIFT SOLENOID A/C COMPRESSOR CLUTCH SOLENOID AXLE DISCONNECT SOLENOID COAST CLUTCH SOLENOID COAST CLUTCH SOLENOID 7 8 COAST CLUTCH SOLENOID (TRANSMISSION HARNESS, NEAR BREAK OUT TO COAST CLUTCH SOLENOID SHIFT SOLENOID 2 COAST CLUTCH SOLENOID SHIFT SOLENOID 2 TRANSMISSION) DISCONNECT SOLENOID DUMP SOLENOID ELECTRONIC PRES- SURE CONTROL SOLENOID ELECTRONIC PRESSURE CONTROL SOLENOID ELECTRONIC PRESSURE CONTROL SOLENOID COAST CLUTCH SOLENOID ELECTRONIC PRESSURE CONTROL SOLENOID SHIFT SOLENOID 1 FORWARD IN-BED FUEL TANK VALVE FUEL RAIL CUTOFF VALVE ISOLATION SOLENOID LEFT REAR AIR SPRING SOLENOID MIDSHIP FUEL TANK VALVE RABS VALVE ASSEMBLY REAR ANTI-LOCK BRAKE SYSTEM PROPORTIONING VALVE SYSTEM ASSEMBLY REAR IN-BED FUEL TANK VALVE RIGHT REAR AIR SPRING SOLENOID SHIFT SOLENOID SHIFT SOLENOID 1 SHIFT SOLENOID 2 STARTER SOLENOID TORQUE CON- VERTER CLUTCH SOLENOID TORQUE CONVERTER CLUTCH SOLENOID TORQUE CONVERTER CLUTCH SOLENOID #2 SHIFT SOLENOID TORQUE CONVERTER CLUTCH SOLENOID SHIFT SOLENOID 2

5 6 7 8 PNK WIRE 22 23 24 25 26 27 28 PNK WIRE BK BLU/ORG WIRE BLK LT BLU/ WIRE BLK ORG/ WIRE BLK WIRE BLK/LT BLU WIRE BLK/LT GRN WIRE BLK/ORG WIRE BLK/PNK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN ORG/ WIRE BRN WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/ORG WIRE BRN/PNK WIRE BRN/WHT WIRE BRN/YEL WIRE COIL WIRE DG GRN/LT GRN WIRE DG GRN/YEL WIRE DK BLU WIRE DK BLU/ ORG WIRE DK BLU/LT GRN WIRE DK BLU/ORG WIRE DK BLU/WHT WIRE DK BLU/YEL WIRE DK GRN WIRE DK GRN/LT GRN WIRE DK GRN/ORG WIRE DK GRN/ORN WIRE DK GRN/PPL WIRE DK GRN/VIO WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE DK PNK/ PNK WIRE GRN WIRE GRN/ LT WIRE GRY RED/ WIRE GRY WIRE GRY/ LT BLU WIRE GRY/BLK WIRE GRY/LT BLU WIRE GRY/ORG WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE INSTRUMENT CLUSTER PNK WIRE LT BLU WIRE LT BLU/ BLK WIRE LT BLU/ WHT WIRE LT BLU/BLK WIRE LT BLU/ORG WIRE LT BLU/PNK WIRE LT BLU/RED WIRE LT BLU/WHT WIRE LT BLU/YEL WIRE LT GRN DK GRN/ WIRE LT GRN RED/ WIRE LT GRN WIRE LT GRN/ BLK WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE LT GRN/PPL WIRE LT GRN/RED WIRE LT GRN/VIO WIRE LT GRN/WHT WIRE LT GRN/YEL WIRE NCA WIRE ORG BLK WIRE ORG PPL/ WIRE ORG YEL/ WIRE ORG/ BRN WIRE ORG/ WIRE ORG/BLK WIRE ORG/LT BLU WIRE ORG/LT GRN WIRE ORG/RED WIRE ORG/WHT WIRE ORG/YEL WIRE PNK 31 32 33 34 35 36 WIRE PNK 929 361 WIRE PNK GAS WIRE PNK LEFT BACKUP LAMP WIRE PNK LEFT REVERSING LAMP WIRE PNK LT WIRE PNK PNK PNK WIRE PNK PNK WIRE PNK PPL WIRE PNK RIGHT BACKUP LAMP WIRE PNK RIGHT REVERSING LAMP WIRE PNK TCSS WIRE PNK WIRE PNK/ LT BLU WIRE PNK/ LT LT WIRE PNK/BLK WIRE PNK/LT BLU WIRE PNK/LT GRN WIRE PNK/ORG WIRE PNK/WHT WIRE PNK/YEL WIRE PPL/ ORG WIRE PPL/ YEL WIRE PPL/LT BLU WIRE PPL/ORG WIRE PPL/WHT WIRE PPL/YEL WIRE RED WIRE RED YEL/ WIRE RED/ GRY WIRE RED/ LT GRN WIRE RED/BLK WIRE RED/LT BLU WIRE RED/LT GRN WIRE RED/ORG WIRE RED/PNK WIRE RED/WHT WIRE RED/YEL WIRE RUN WIRE SHIFT SOL TC SPD SENS PNK WIRE TAN WIRE TAN/ LT BLU WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/LT GRN WIRE TAN/ORG WIRE TAN/RED WIRE TAN/WHT WIRE TAN/YEL WIRE VIO WIRE VIO/LT GRN WIRE VIO/ORG WIRE VIO/WHT WIRE VIO/YEL WIRE WHT GRY/ WIRE WHT LT BLU/ WIRE WHT WIRE WHT YEL/ WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/ORG WIRE WHT/PNK WIRE WHT/PPL WIRE WHT/RED WIRE WHT/YEL WIRE YEL (OR WIRE YEL PPL WIRE YEL RED/ WIRE YEL WIRE YEL/ ORG WIRE YEL/ WHT WIRE YEL/BLK WIRE YEL/LT BLU WIRE YEL/LT GRN WIRE YEL/RED WIRE YEL/WHT WIRE

0.6 OHMS 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 ILUMINATION GROUND FUSED IGNITION 1 2 3 4 5 6 7 8 9 10 SHIFT SOL 1 VEHICLE PWR TCC SOL 1.2 OHMS 2.7 OHMS 3.8 OHMS 4 7 W/ RAP W/O RAP 4 WHEEL ABS REAR ABS 4 X 4 HIGH IND 4.0 OHMS 4.2L 4.2L 4.6L 4.2L 4.6L 5.4L 4.2L, 5.4L NGV OTHERS 4.9L, 5.0L, 5.8L UNDER 8500 GVWR 5.4L 5.4L 2V ONLY 5.4L NGV 5.4L NGV GAS 5.8L OVER 8500 LBS, 7.5L 7.5L, 5.8L OVER 8500 GVWR 8 9 10 307 57 BRAKE PRESS IN GROUND 13 4 16 IGN BAT BAT 20 OHMS 22.5 A C.B. 120 OHMS 120 OHMS OHMS 270 OHMS 360 OHMS OHMS 500 OHMS 500 OHMS BRAKE FLUID LEVEL 676 523 2 4 5 7 GROUND VSS INPUT VSS INPUT VSS OUTPUT 679 306 151 848 295 VEHICLE SPEED INPUT BRAKE APPLIED IN 680 OHMS 820 OHM 820 OHMS 875 875 14 26 GROUND GROUND 1000 OHMS 1400 OHM 2200 OHMS #5 #8 (14 GA- (LEFT SIDE OF SAFETY (MAIN BODY HARN, NEAR BREAKOUT LT (MAIN HARN, NEAR BREAKOUT TO CLUSTER (TRANSMISSION HARNESS, NEAR (TRANSMISSION HARNESS, NEAR BREAK OUT TO (W/ TRAILER TOW * VEHICLES OVER 8500 GVWR ** VEHICLES UNDER 8500 GVWR A/C COMPRESSOR CLUTCH A/C CYL PRESS SW A/T M/T ACCEL SIG ACCL PDL POS SENS AIR BAG IND AIR BAG SLIDING CONTACT AIR CONDITIONING SYSTEM AIRBAG IND AIRBAG SLIDING CONTACT ALL ENGINES ALL EXCEPT BRONCO ALL OTHER ASHTRAY ILLUMINATION AUDIO ON AUDIO SYSTEM ON PROTOCOL A PROTOCOL B AUTOLAMP MODULE AUX PWRTRN IN BACKUP LAMPS BENCH SEAT W/ LUMBAR BIAS CKT BLEND DOOR POTENTIOMETER BODY COMPUTER BODY COMPUTER SYSTEM BPP SW INPUT TCEC RLY CTRL BRAKE IND BRAKE IND OUT BRAKE ON/OFF SW IN BRAKE PRESS SW BRAKE WARN IN BRAKE WARNING IND BRONCO ONLY CAB MARKER LAMPS CAM POS SENS CAPTAIN CHAIRS W/ POWER BOLSTERS CAPTAIN CHAIRS W/ POWER LUMBAR CARGO/ HIGH MOUNT STOP LAMPS CD CHANGER CENTRAL JUNCTION BOX CENTRAL TIMER MODULE/ GENERIC ELECTRONIC MODULE CHARGE IND CHARGING CIRCUIT CHARGING SYSTEM CHASSIS CAB CHECK SUSPENSION IND CHK ENG GEN DATA PPL CHT VPWR PWR GND EPC OSS TP VREF SIG RTN BOO VPWR PWR GND CHT VPWR PWR GND PWR GND TCIL EPC OSS TP VREF SIG RTN BOO VPWR PWR GND CHT VPWR PWR GND TCIL EPC OSS TP VREF SIG RTN BOO VPWR PWR GND CID SIG CID SIG IN CIGAR LIGHTER CIRCUIT BREAKER 12 CIRCUIT BREAKER 14 CKP- CKP+ CLOCK SPRING ASSEMBLY CLUTCH PDL POSIT SW BRAKE PRESS SW CLUTCH PEDAL POSITION CMP RTN CNTRL SW OUT COAST CLUTCH CONTROL COMPUTER DATA LINES COMPUTER DATA LINES SYSTEM CONN A CONN B CONN C CONTROL SW IN CONTROL SW GND IGN COOLANT TEMP GAUGE CREW CAB ONLY CREW CAB W/ XLT CREW CAB W/ XLT CREW CAB W/O XLT CREW CAB W/ XLT CREW CAB W/O XLT CRUISE CONTROL SYSTEM CSE GND IAT VREF DATA TR TCIL IGN EPC GND TCS TFT MAP SIG RTN TP DATA CTM DIAGNOSTIC IN CTRL SW OUTPUT DATA LINK DATA LINK FEPS DEF VENT DIAGNOSTIC CIRCUIT NOT USED BRAKE FLUID LEVEL SW DIESEL ENGINES DIESEL ONLY DIESEL ONLY BRONCO ONLY DIESEL W/ TACH DIESEL WARNING LAMPS DISPLAY DISARM IN DISTRIBUTOR IGNITION SHIELD DK LT DN UP DOOR AJAR IND DOOR AJAR INPUT DOOR AJAR OUT DOOR AJAR REVERSE IN DOOR LOCKS DOOR LOCKS SYSTEM DOWN RIGHT DRIVER AIR BAG DRVR UNLOCK DUMP SOL ELECT. SHIFT ELECTRIC BRAKES ELECTRONIC SHIFT ELECTRONIC SHIFT MANUAL SHIFT ELECTRONIC SUSPENSION SYSTEM ENG COOLANT TEMP GAUGE ENTIRE SEAT EXCEPT DIESEL BRAKE WARNING IND. EXPEDITION, NAVIGATOR F-350 W/ DUAL REAR WHEELS F-SERIES F-SERIES BRONCO F-SERIES ONLY FASTEN SAFETY BELT IND FASTEN SEAT BELT IND. ILLUMINATION LAMPS FLASH TO PASS FLOOR MIX OFF FOG ON IND FRAME) FROM AIR BAG DIAGNOSTIC MONITOR FRONT OF SEAT FRONT TANK FUEL GAUGE SENDER FUEL DELIVERY SIG FUEL GAUGE FUEL INJ FEED LEFT FUEL INJ FEED RIGHT FUEL INJECTOR 1 FUEL INJECTOR 2 FUEL INJECTOR 3 FUEL INJECTOR 4 FUEL INJECTOR 5 FUEL INJECTOR 6 FUEL INJECTOR 7 FUEL INJECTOR #8 FUEL INJECTOR #1 FUEL INJECTORS FUEL PRESS FUEL RESET IND FUEL TANK PRESS FUEL TEMP FUSIBLE LINK A FUSIBLE LINK A (12 GA- FUSIBLE LINK B FUSIBLE LINK B (12 GA- FUSIBLE LINK J FUSIBLE LINK K FWD RWD GAS OVER 8500 GVWR GAS UNDER 8500 GVWR AND ALL DIESEL GASOLINE AND DIESEL W/O TRACTION CONTROL ONLY GASOLINE ENGINES GASOLINE ONLY GASOLINE OVER 8500 GVWR GASOLINE UNDER 8500 GVWR AND ALL DIESEL GEM ONLY GEM ONLY CTM ONLY GEN DATA AUX DATA GND GENERIC ELECTRONIC MODULE GENERIC ELECTRONIC MODULE/ CENTRAL TIMER MODULE GENERIC SCAN TOOL GLOW PLUG CONTROLLER GLOW PLUG CTRL GROUND VSS INPUT VSS INPUT VSS OUTPUT HEAD OFF HEAD PARK HEADLIGHTS SYSTEM HEATED OXYGEN HI HEADLAMP HI HI LO LO HI LO HI PARK HI PASS LO HI-BEAM IND HIGH BEAM IND HIGH MOUNTED STOPLAMP HORNS SYSTEM HORNS, ANTI-THEFT, DOOR LOCKS SYSTEMS HOT AT ALL TIMES HOT IN HOT IN ACC OR RUN HOT IN ACCY OR RUN HOT IN HOT AT ALL TIMES HOT IN RUN HOT IN RUN AR ACC HOT IN RUN OR ACC HOT IN RUN OR START HOT IN START OR RUN HOT W/ LIGHT SW IN HEAD OR PARK HRN RLY ICP+ IDLE VALIDATION SW IDM ENABLE OUT IDM FEEDBACK SIG IDM SIG IN IGNITION COILS IGNITION COILS 1, 2 IGNITION COILS 3, 4 IGNITION COILS, RADIO NOISE CAPACITOR IGNITION COILS, RADIO NOISE CAPACITOR OR NGV TIMER IGNITION RADIO COILS NOISE 3, 4 CAPACITOR ILLUM ENTRY IN ILLUMI- NATION ILLUMINATED ENTRY REQUEST IN IND FEED INJ 1 INPUT INJ 1 OUT INJ 2 INPUT INJ 2 OUT INJ 3 INPUT INJ 3 OUT INJ 4 INPUT INJ 4 OUT INJ 5 INPUT INJ 5 OUT INJ 6 INPUT INJ 6 OUT INJ 7 INPUT INJ 7 OUT INJ 8 INPUT INJ 8 OUT INJ SHIELD GND INJECTOR DRIVER MODULE INJECTORS FUEL INSTRUMENT CLUSTER INSTRUMENT CLUSTER FASTEN BELTS INDI- CATOR INSTRUMENT CLUSTER SYSTEM INSTRUMENT CLUSTER, ANTI- THEFT SYSTEM INTAKE MANIFOLD EVR CTRL INTAKE MANIFOLD RUNNER CONTROL INTERVAL DELAY/WASH WIPER MODE SELECT ISO SOL L/R ILLUM U/D L/R U/D LEFT DOOR AJAR LEFT EXTERIOR REAR VIEW MIRROR LEFT FRONT LEFT FRONT SIDE MARKER LAMPS LEFT HEADLAMP LEFT HEADLAMP RIGHT HEADLAMP LEFT POWER LEFT POWER LUMBAR/BOLSTER LEFT SIDE BODY MARKER LAMPS LEFT TURN IND LEFT TURN SIGNAL OUTPUT LICENSE LAMPS LO HEADLAMP LO HI LO HI HI LO HI INSTRUMENT CLUSTER LEFT HEADLAMP LO HI LEFT HEADLAMP LO HI RIGHT HEADLAMP LO LEFT HEADLAMP LOW FUEL IND LOW OIL/HIGH COOLANT IND LOW RANGE IND. LT LT LT LT DK LT LT LT LT LT LT LT LT PPL M/T A/T MAF SENS IN TP SENS IN MAF SENS IN TP SENS IN REF VOLT SIG RTN BRAKE ON/OFF MAF TFT MAGNETIC CLUTCH MANUAL SHIFT MAP LAMPS MAP LAMPS INSTRUMENT CLUSTER MAP LAMPS WITH XL, XLT ONLY) MARKER LAMPS MECH. SHIFT MECHANICAL SHIFT ONLY MED HI MED LO MICRO- PROCESSOR MIL DATA FEPS PPL MIL DATA PPL MIL VRS RTN DATA MIX DEF MIX NORM DEF MAX NGV MODULE NGV TIMER NORM MAX NOT USED NOT USED CYL HEAD TEMP O/D OFF IND OD OFF OFF FLOOR OFF FLOOR VENT OFF HEAD PARK OFF LO INT MAX INT MIN OHMS OFF ON 2200 OHMS OFF PANEL/FLOOR PANEL FLOOR A/C FLR/DEF MAX A/C DEFROST OFF PARK OIL PRESS GAUGE ON OFF ON UPPER RADIATOR SUPPORT) ONE- TOUCH DOWN OTHER 4.6L OUTSIDE CARGO/ HIGH MOUNT STOP LAMPS OVER- HEAD CONSOLE PANEL, FLOOR OFF PANEL FLOOR FLR, DEF A/C DEF MAX A/C PARK BRAKE INPUT PARK BRAKE SW IN PARK SENSE PASS HI LO PASS LO PASSENGER AIR BAG PCM DLC PICK-UP W/ DUAL REAR WHEELS ONLY PIN 3 FOR 5.4L NGV PLUGGED FUEL FILTER IND. POWER DISTRIBUTION POWER DISTRIBUTION BOX POWER WINDOWS SYSTEM POWER WINDOWS SYSTEM POWER WINDOWS SYSTEM POWERTRAIN CONTROL LEFT MODULE HEADLAMP PPL 13 10 2 PPL 342 PPL PPL PREMIUM SOUND ONLY PROCESSOR MICRO- PROGRAM- MABLE SPEEDO- METER/ ODOMETER MODULE PROGRAMMABLE SPEEDOMETER/ ODOMETER MODULE PROTOCOL A PROTOCOL B PSOM MODULE PSOM VEHICLE SPEED OUTPUT PULL- IN PWR GND PWR GND TCC KAPWR VSS PWR GND TCC TCSS PWR GND TCC TSS PWR GRD RADIO CAPACITOR RADIO NOISE CAPACITOR RADIO NOISE CAPACITOR 1 RADIO NOISE CAPACITOR 2 RADIO PREMIUM SOUND AMPLI- FIER REAR AIR SUSPENSION MODULE REAR AIR SUSPENSION MODULE INSTRUMENT CLUSTER REAR BODY MARKER LAMPS REAR OF SEAT REAR TANK FUEL GAUGE SENDER REAR WINDOW DEFROST CONTROL REF VOLTAGE BPP SW REMOTE ANTI-THEFT PERSONALITY MODULE REMOTE ANTI-THEFT PERSONALITY MODULE RADIO REMOTE KEYLESS ENTRY MODULE RHEOSTAT OUT RHEOSTAT OUTPUT RIGHT DOOR AJAR RIGHT EXTERIOR REAR VIEW MIRROR RIGHT FRONT RIGHT FRONT PARK/ TURN RIGHT FRONT SIDE MARKER LAMPS RIGHT HEADLAMP RIGHT POWER RIGHT REAR PARK/ STOP/ TURN RIGHT SIDE BODY MARKER LAMPS RIGHT SIG RIGHT TURN IND RIGHT TURN SIGNAL OUTPUT RPM CTRL RPM INPUT RX INPUT TX INPUT SCAN TOOL GENERIC SET/ ACCEL SET/ COAST ACCEL SHIFT CONTROL 1 SHIFT CONTROL 2 SHIFT SOL TRANS CTRL IND DLC SHIFT SOLENOIDS SHIFT SOLND #2 SHIFT SOLND #1 SHORTING BAR SIG RETURN SIG RETURN BPP SW SIG RTN SIGNAL RETURN SINGLE TANK SOLID STATE SOTF RLY CTRL SPARK PLUGS SPEED CONT GND VEHICLE SPEED SENS SPEED CONT COM SIG SPEED CTRL GND SSA SSB STARTING SYSTEM STARTING/ CHARGING STARTING/ CHARGING SYSTEM STEERING ASSEMBLY STEERING COLUMN ASSEMBLY STEERING COLUMN GROUND STYLE SIDE, FLARE SIDE SUPPORT) SW D INPUT SW C INPUT SW B INPUT SW A INPUT NEUTRAL SW IN TAMPER SW TANKS ONLY TCC CCS IGN GND TCC CPPS VSS GND MAP TFT TCIL DATA TCIL IND DLC TCS CASE GND TFT ECT IAT TCS OR CPP TCS TFT IAT TFT IAT TFT IAT ECT TO TRAILER LEFT TURN LAMPS TO TRAILER RIGHT TURN LAMPS TONE REQUEST TRAILER ELECTRONIC BRAKE CONTROL TRAILER ELECTRONIC BRAKE CONTROL TRAILER/ CAMPER ADAPTER TRAILER GROUND TRAILER PROVISION TRAILER PROVISIONS TRAILER TOW TRAILER TOW ILLUMINATION FEED TRAILER/ CAMPER ADAPTER TRAILER ELECTRONIC BRAKE CONTROL TRAILER/CAMPER ADAPTER TRANS- MISSIONS SYSTEM TRANS- MISSIONS SYSTEM 784 915 TRANSFER CASE ASSEMBLY TRANSFER CASE CIRCUIT TRANSFER CASE SHIFT MODULE TRANSMISSION TRANSMISSION TRANSMISSIONS SYSTEM TSS SPD SENS UP DOWN UP LEFT UP UP DN VEHICLE SPEED SIG VIP DATA LINK VOLT- METER VPWR FUEL INJ 7 FUEL INJ 5 FUEL INJ 3 FUEL INJ 1 VPWR FUEL INJ 8 FUEL INJ 6 FUEL INJ 4 FUEL INJ 2 VPWR NGV MODULE NGV MODULE NGV MODULE NGV MODULE VPWR PWR GND PWR GND EPC TP VREF SIG RTN BOO VPWR PWR GND VPWR PWR GND PWR GND TCIL EPC OSS TP VREF SIG RTN BOO VPWR PWR GND VSS GND VSS INPUT VSS OUT GND VSS OUTPUT W/ A/C W/O A/C W/ CARGO LAMPS W/ DRL W/O DRL W/ DUAL W/ ELECTRONIC SHIFT CONTROL W/ FLARE SIDE W/ FLARE SIDE ONLY W/ MANUAL TRANSMISSION W/ PREMIUM SOUND W/ RABS ONLY W/ RAP W/ RAP MODULE W/O RAP MODULE W/ REAR BUMPER W/ REAR BUMPER ONLY W/ REMOTE KEYLESS ENTRY W/ SHIFT- ON-THE FLY W/ SUPER CAB W/ TACH W/ TRAILER TOW ONLY W/ W/O W/O CARGO LAMPS W/O CREW CAB W/O POWER GROUP W/O PREMIUM SOUND W/O RAP W/O RAP MODULE W/ RAP MODULE W/O REAR BUMPER W/O REAR BUMPER ONLY W/O REMOTE KEYLESS ENTRY W/O SUPER CAB W/O TACH W/TRAILER TOW ONLY WAIT TO START IND WAIT TO START OUT WALL) WARM COLD WARNING CHIME MODULE WATER IN FUEL IND WITH AUTO LAMPS WITH CAPTAIN'S CHAIR WITH ELECTRONIC SHIFT ONLY WITH POWER BOLSTER WITH CLOTH BENCH WITH POWER LUMBAR SEATS WITH REAR BUMPER ONLY WITH REMOTE KEYLESS ENTRY WITH REMOTE KEYLESS ENTRY ONLY
