Ford Pickup F250 Super Duty (1999-1999) wiper hi/lo relay Wiring diagram
This page shows the only wiring diagram for the component.wiper hi/lo relay, which is found in the car Ford Pickup F250 Super Duty (1999-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wiper hi/lo relay (1 of 1)
4 WHEEL DRIVE MODE SWITCH
BLK WIRE
BRAKE/RUN RELAY
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DK BLU WIRE
DK BLU/ ORG WIRE
FUSE 11
GENERIC ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH)
GRY/ LT BLU WIRE
GRY/LT BLU WIRE
HI PARK
HI WASHER SWITCH OFF INT MAX LO OHMS INT MIN
HOT IN ACC OR RUN
INTERVAL DELAY/WASH WIPER MODE SELECT
LT BLU WIRE
LT BLU/ORG WIRE
MULTI- FUNCTION SWITCH WIPER SWITCH
OFF LO INT MAX INT MIN OHMS
OHMS
PARK SENSE
PNK/YEL WIRE
RED WIRE
RUN WIRE
SIGNAL RETURN
TAN WIRE
TAN/RED WIRE
WASHER PUMP ASSEMBLY
WASHER PUMP RELAY
WHT WIRE
WINDSHIELD WIPER MOTOR
WIPER HI/LO RELAY
WIPER RUN/PARK RELAY
WIPER SPEED WASHER PUMP
YEL WIRE
YEL/WHT WIRE
