Ford Pickup F250 Super Duty (1999-1999) main light switch dimmer module Wiring diagram
This page shows the only wiring diagram for the component.main light switch dimmer module, which is found in the car Ford Pickup F250 Super Duty (1999-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram main light switch dimmer module (1 of 1)
AIRBAG SLIDING CONTACT
ASHTRAY ILLUMINATION
ASSEMBLY
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BRN WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) FUSE 18
DK BLU/WHT WIRE
DRIVE MODE SWITCH
FUNCTION SELECTOR SWITCH
FUSE 6
HEAD OFF
HOT AT ALL TIMES
INSTRUMENT CLUSTER (6 BULBS)
LEFT POWER DOOR LOCK SWITCH
LEFT POWER WINDOW SWITCH
LT BLU WIRE
LT BLU/BLK WIRE
LT BLU/RED WIRE
MAIN LIGHT SWITCH
MAIN LIGHT SWITCH DIMMER MODULE
NCA WIRE
PARK
PARK LAMP RELAY
RADIO
RED WIRE
RIGHT POWER DOOR LOCK SWITCH
RIGHT POWER WINDOW SWITCH
STEERING COLUMN ASSEMBLY
TAN/WHT WIRE
TRAILER TOW ILLUMINATION FEED
Go to component -> Instrument illumination circuit -> MAIN LIGHT SWITCH DIMMER MODULE
