Ford Pickup F250 Super Duty (1999-1999) idle air ctrl oss sensor cmp sensor Wiring diagram

270 OHMS BATTERY JUNCTIOIN BOX (IN LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/LT BLU WIRE BLK/PNK WIRE BLK/WHT WIRE BRAKE PEDAL POSITION (BPP) SWITCH BRN/LT GRN WIRE BRN/WHT WIRE CAMSHAFT POSITION (CMP) SENSOR (ON FRONT OF ENGINE) CAMSHAFT POSITION SENSOR SHIELD CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) DIGITAL TRANSMISSION RANGE SENSOR (DTR SENSOR-A/T) (LEFT SIDE OF TRANSMISSION) DK BLU/YEL WIRE DK GRN WIRE DK GRN/VIO WIRE DK GRN/WHT WIRE EFT SENSOR INJ PRESSURE ENGINE FUEL TEMPERATURE (EFT-A) SENSOR (ON TOP OF ENGINE) FROM DTR SENSOR (DIAGRAM 1 OF 5) FUSE 15 FUSE 2 GRY WIRE GRY/BLK WIRE GRY/LT BLU WIRE GRY/RED WIRE GRY/WHT WIRE HEATED OXYGEN SENSOR HEATED OXYGEN SENSOR HOT AT ALL TIMES IDLE AIR CONTROL VALVE (ON LEFT SIDE OF INTAKE MANIFOLD) IDLE AIR CTRL OSS SENSOR CMP SENSOR LT BLU WIRE LT BLU/ORG WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN/YEL WIRE MAF SENS IN TP SENS IN MASS AIR FLOW (MAF) SENSOR (IN AIR CLEANER ASSEMBLY) NCA WIRE NOT USED CYL HEAD TEMP PNK WIRE PNK/BLK WIRE PNK/LT BLU WIRE PNK/WHT WIRE PNK/YEL WIRE POWERTRAIN CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT) PWR GND IGN COIL 2 PWR GND IGN COIL 7 IGN COIL 8 FUEL CTRL EPC SOL RED WIRE RED/BLK WIRE RED/LT GRN WIRE RED/PNK WIRE RED/WHT WIRE RED/YEL WIRE SIG RTN BPP SWITCH TAN/LT BLU WIRE TSS SENSOR VIO/YEL WIRE VPWR NGV MODULE NGV MODULE NGV MODULE NGV MODULE VSS (+) WOT RELAY VSS INPUT WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/RED WIRE WHT/YEL WIRE WOT RELAY YEL WIRE YEL/BLK WIRE YEL/LT BLU WIRE YEL/LT GRN WIRE YEL/RED WIRE
