Ford Pickup F250 Super Duty (1999-1999) function selector switch assembly blend door actuator speed control servo Wiring diagram

A/T BATTERY JUNCTION BOX BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) BLK/LT GRN WIRE BLK/PNK WIRE BLOWER RELAY BLOWER/ FLASHER RELAY BLOCK CENTRAL JUNCTION BOX CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) DELAY RELAY DG GRN/LT GRN WIRE DK BLU/LT GRN WIRE DK GRN WIRE DK GRN/LT GRN WIRE ELECTRONIC SHIFT FROM FUSE 101 (DIAGRAM 1 OF 4) FUNCTION SELECTOR SWITCH ASSEMBLY BLEND DOOR ACTUATOR SPEED CONTROL SERVO FUSE 102 FUSE 103 FUSE 108 FUSE 112 FUSE 104 FUSE 105 FUSE 11 FUSE 110 FUSE 111 FUSE 113 FUSE 2 FUSE 1 FUSE 21 FUSE 5 FUSE 6 FUSE 8 GENERIC ELECTRONIC MODULE GRY/YEL WIRE IGNITION SWITCH LOCK OFF LT BLU/ORG WIRE LT BLU/PNK WIRE LT GRN/PPL WIRE M/T MANUAL SHIFT NCA WIRE ORG/YEL WIRE PCM POWER RELAY FUEL PUMP RELAY REAR AIR SUSPENSION MODULE INSTRUMENT CLUSTER REAR WHEEL ANTI-LOCK BRAKES SYSTEM MODULE RED WIRE RED/BLK WIRE RED/LT BLU WIRE REMOTE ANTI-THEFT PERSONALITY MODULE RADIO REVERSING LAMP SWITCH RPO RELAY BLOCK RUN WIRE SHIFT LOCK ACTUATOR SHIFT-ON- THE-FLY RELAY STARTING SYSTEM TAN/BLK WIRE TO FUSE 2 (DIAGRAM 3 OF 4) TO FUSE 22 (DIAGRAM 4 OF 4) TO FUSE 29 (DIAGRAM 3 OF 4) TRAILER ADAPTER (ELECTRONIC BRAKE CONTROL) POWER SEAT CONTROL SWITCH TRANSFER CASE ELECTRIC CLUTCH RELAY TRANSFER CASE SHIFT MODULE WASHER PUMP RELAY WHT/BLK WIRE WHT/PNK WIRE WINDSHIELD WIPER MOTOR WIPER RUN/PARK RELAY WIPER HI/LO RELAY WOT RELAY DIGITAL TRANS- MISSION RANGE SENSOR BATTERY JUNCTION BOX YEL WIRE YEL/BLK WIRE
