Ford Pickup F250 Super Duty (1999-1999) direc- tional control switch Wiring diagram
This page shows the only wiring diagram for the component.direc- tional control switch, which is found in the car Ford Pickup F250 Super Duty (1999-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram direc- tional control switch (1 of 1)
BLK WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DIREC- TIONAL CONTROL SWITCH
DK BLU WIRE
DK GRN WIRE
DOWN RIGHT
EXTERIOR LIGHTS
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE
HOT AT ALL TIMES
ILLUM
L/R ILLUM U/D
L/R U/D
LEFT
LEFT EXTERIOR REAR VIEW MIRROR
NCA WIRE
ORG/LT GRN WIRE
RED WIRE
RIGHT
RIGHT EXTERIOR REAR VIEW MIRROR
UP LEFT
VIO WIRE
WHT/LT BLU WIRE
YEL WIRE
Go to component -> Power mirror circuit -> DIREC- TIONAL CONTROL SWITCH
