Ford Pickup F250 Super Duty (1999-1999) diagnostic circuit not used brake fluid level sw Wiring diagram

1 2 GROUND POWER (B+) 1400 OHM 4 WHEEL ANTI-LOCK BRAKES 4 X 4 HIGH IND 820 OHM ANTI- LOCK IND BIAS CKT BATTERY JUNCTION BOX (ON LEFT SIDE OF ENGINE COMPARTMENT) FUSE 102 BLK WIRE BLK/LT BLU WIRE BLK/PNK WIRE BRAKE FLUID LEVEL INDICATOR SWITCH (ON BRAKE FLUID RESERVOIR) BRAKE PEDAL POSITION (BPP) SWITCH (UNDER LEFT SIDE OF DASH) CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR DIAGNOSTIC CIRCUIT NOT USED BRAKE FLUID LEVEL SW DIFFERENTIAL SPEED SENSOR (DSS) (ON REAR AXLE) DK GRN WIRE DK GRN/YEL WIRE FUSE 15 FUSE 25 FUSE 6 GRY/YEL WIRE HOT AT ALL TIMES HOT IN RUN IGNITION FEED BPP SWITCH FEED INSTRUMENT CLUSTER LEFT FRONT LT BLU/WHT WIRE LT GRN/BLK WIRE LT GRN/YEL WIRE NOT USED ORG/YEL WIRE PROCESSOR MICRO- REAR SENSOR (LOW) RIGHT FRONT SENSOR (LOW) LEFT FRONT SENSOR (LOW) RED/LT GRN WIRE RED/PNK WIRE RIGHT FRONT SENSOR (AT WHEEL) TAN/BLK WIRE TAN/LT GRN WIRE TAN/ORG WIRE TAN/RED WIRE WHT WIRE WHT/ORG WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/RED WIRE
