Ford Pickup F250 Super Duty (1999-1999) charging system Wiring diagram

4 WHEEL ANTI- LOCK BRAKE SYSTEM MODULE (ON LEFT SIDE OF ENGINE COMPT) 5.4L NGV GAS 820 OHMS AIRBAG IND ANTI-LOCK IND BIAS CKT BLK WIRE BLK/ORG WIRE BLK/YEL WIRE BLU WIRE BRAKE FLUID LEVEL INDICATOR SWITCH (ON BRAKE FLUID RESERVOIR) BRAKE IND CENTRAL JUNCTION BOX FUSE 30 CHARGE IND CHARGING SYSTEM CHECK SUSPENSION IND COMPUTER DATA LINES SYSTEM CONN A CONN B DK GRN WIRE DK GRN/LT GRN WIRE DK GRN/ORG WIRE DK GRN/YEL WIRE DOOR AJAR IND ENGINE OIL PRESSURE SWITCH (ON LEFT FRONT OF ENGINE) FASTEN SAFETY BELT IND FUEL PUMP ASSEMBLY (UNDER VEHICLE, AT FUEL TANK) FUEL PUMP MODULE FUEL RESET IND FUSE 2 FUSE 6 GENERIC ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH) GRY WIRE GRY/ORG WIRE GRY/WHT WIRE GRY/YEL WIRE HEADLIGHTS SYSTEM HI-BEAM IND HOT AT ALL TIMES HOT IN RUN HOT IN START OR RUN ILLUMINATION INERTIA FUEL SHUTOFF SWITCH (UNDER RIGHT SIDE OF DASH) INSTRUMENT CLUSTER LEFT TURN IND LOW FUEL IND LOW OIL/HIGH COOLANT IND LT BLU WIRE LT BLU/RED WIRE LT GRN WIRE LT GRN/RED WIRE LT GRN/WHT WIRE MALFUNCTION INDICATOR MICRO- PROCESSOR MICROPROCESSOR NCA WIRE NGV MODULE (ON FRONT OF ENGINE) PARK BRAKE SWITCH (ON RIGHT SIDE OF PARKING BRAKE LEVER) PASSIVE ANTI-THEFT SYSTEM TRANSCEIVER MODULE (BEHIND LEFT SIDE OF DASH) PNK/LT BLU WIRE PNK/ORG WIRE REAR AIR SUSPENSION MODULE (BEHIND CENTER OF DASH) REAR ANTI- LOCK BRAKE SYSTEM MODULE (BEHIND RIGHT SIDE OF DASH) RED WIRE RED/LT GRN WIRE RED/WHT WIRE RESTRAINTS CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) RIGHT TURN IND RX INPUT TX INPUT TAN WIRE TAN/LT GRN WIRE TAN/ORG WIRE THEFT INDICATOR MICRO CLUSTER WHT WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/RED WIRE YEL WIRE YEL/WHT WIRE
