Ford Pickup F250 Super Duty (1999-1999) battery junction box fog lamp relay Wiring diagram
This page shows the only wiring diagram for the component.battery junction box fog lamp relay, which is found in the car Ford Pickup F250 Super Duty (1999-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram battery junction box fog lamp relay (1 of 1)
BATTERY JUNCTION BOX FOG LAMP RELAY
BLK WIRE
CENTRAL JUNCTION BOX
DAYTIME RUNNING LAMPS RELAY 1
DAYTIME RUNNING LAMPS RELAY 2
DAYTIME RUNNING LAMPS RELAY BLOCK (BEHIND RIGHT SIDE OF DASH)
DAYTIME RUNNING LAMPS RESISTOR (IN LEFT FRONT OF ENGINE COMPT)
DK BLU WIRE
DK BLU/ORG WIRE
DK GRN WIRE
EXPEDITION, NAVIGATOR
FOG LAMP SW
FOG ON IND
FUSE 16
FUSE 27
FUSE 28 FUSE 26
FUSE 3
FUSE 5
GRY WIRE
GRY/WHT WIRE
HI BEAM INDICATOR
HI LO
HI PASS LO
HOT AT ALL TIMES
HOT AT ALL TIMES BATTERY JUNCTION BOX FUSE 9
HOT IN RUN
INSTRUMENT CLUSTER
LEFT FOG LAMP
LEFT HEADLAMP
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
OFF HEAD PARK
ORG/ WIRE
ORG/LT GRN WIRE
PASS
PNK WIRE
RED WIRE
RED/YEL WIRE
RIGHT FOG LAMP
RIGHT HEADLAMP
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Headlamps & fog lamps circuit, with drl -> BATTERY JUNCTION BOX FOG LAMP RELAY
