Ford Pickup F250 Super Duty (1999-1999) anti- bias circuit lock ind Wiring diagram

1.2 OHMS 4 X 4 HIGH IND 4.0 OHMS ANTI- BIAS CIRCUIT LOCK IND BLK WIRE BLK/LT BLU WIRE BLK/ORG WIRE BLK/PNK WIRE BLK/WHT WIRE BRAKE FLUID LEVEL INDICATOR SWITCH (ON BRAKE FLUID RESERVOIR) BRAKE PEDAL POSITION (BPP) SWITCH (UNDER LEFT SIDE OF DASH) CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) DIFFERENTIAL SPEED SENSOR (ON REAR AXLE) DIFFERENTIAL SPEED SENSOR DATA LINK CONNECTOR (IN CENTRAL JUNCTION BOX) DK GRN WIRE DK GRN/YEL WIRE DUMP SOL FUSE 15 FUSE 6 GRY/YEL WIRE HOT AT ALL TIMES HOT IN RUN IGNITION SWITCH INSTRUMENT CLUSTER ISO SOL LOCK OFF LT BLU WIRE LT BLU/PNK WIRE LT BLU/RED WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/YEL WIRE NCA WIRE NOT USED PNK/LT GRN WIRE REAR ANTI-LOCK BRAKE SYSTEM (RABS) MODULE (BEHIND RIGHT SIDE OF DASH) RED WIRE RED/LT GRN WIRE RED/PNK WIRE RUN WIRE TAN WIRE TAN/LT GRN WIRE VALVE RESET SWITCH WHT WIRE YEL WIRE YEL/LT GRN WIRE
