Ford Pickup F150 (1996-2012) 5.8l, charging circuit

500 OHMS BATTERY BLK WIRE BLK/ORG WIRE CHARGE INDICATOR ENGINE COMPARTMENT FUSE BOX FUSE 17 FUSIBLE LINK A FUSIBLE LINK B FUSIBLE LINK J GENERATOR, VOLTAGE REGULATOR IGNITION SWITCH INSTRUMENT CLUSTER LOCK OFF LT GRN/RED WIRE RED WIRE RED/LT GRN WIRE RUN WIRE STARTER RELAY WHT/BLK WIRE YEL WIRE YEL/WHT WIRE
